9YA0 image
Deposition Date 2025-09-15
Release Date 2025-11-19
Last Version Date 2025-12-24
Entry Detail
PDB ID:
9YA0
Title:
Cryo-EM structure of pre-conoid ring 2 (PCR P2 ring)from Toxoplasma gondii
Biological Source:
Source Organism(s):
Method Details:
Experimental Method:
Resolution:
3.54 Å
Aggregation State:
FILAMENT
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR5, TGME49_242320
Gene (Uniprot):TGME49_242320
Chain IDs:A (auth: AA), D (auth: AD), E (auth: AE), H (auth: AH), I (auth: AI), L (auth: AL)
Chain Length:1073
Number of Molecules:6
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR4, TGME49_201220
Gene (Uniprot):TGRH88_037430
Chain IDs:B (auth: AB), C (auth: AC), F (auth: AF), G (auth: AG), J (auth: AJ), K (auth: AK)
Chain Length:603
Number of Molecules:6
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Formin 1
Gene (Uniprot):FRM1
Chain IDs:M (auth: BA), N (auth: BB), O (auth: BC), P (auth: CA), Q (auth: CB), R (auth: CC), S (auth: CE), T (auth: CF), U (auth: CG), V (auth: CI), W (auth: CJ), X (auth: CL)
Chain Length:5051
Number of Molecules:12
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR11, TGME49_209490
Gene (Uniprot):TGPRC2_209490
Chain IDs:Y (auth: DA), Z (auth: DB), AA (auth: DC), BA (auth: DD), CA (auth: DE), DA (auth: DF)
Chain Length:505
Number of Molecules:6
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CGP, TGME49_240380
Gene (Uniprot):TGME49_240380
Chain IDs:EA, FA (auth: EB), GA (auth: EC)
Chain Length:4956
Number of Molecules:3
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:FLM1, TGME49_271780
Gene (Uniprot):TGME49_271780
Chain IDs:HA (auth: FA), IA (auth: FB), JA (auth: FC), KA (auth: FD), LA (auth: FE), MA (auth: FF)
Chain Length:2777
Number of Molecules:6
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Transport protein Sec24
Gene (Uniprot):TGRH88_066320
Chain IDs:NA (auth: GA), PA (auth: GC), RA (auth: GE), TA (auth: GG), VA (auth: GI), XA (auth: GK)
Chain Length:1019
Number of Molecules:6
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Protein transport protein SEC23
Gene (Uniprot):TGME49_291680
Chain IDs:OA (auth: GB), QA (auth: GD), SA (auth: GF), UA (auth: GH), WA (auth: GJ), YA (auth: GL)
Chain Length:791
Number of Molecules:6
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:FLM2, TGME49_285990
Gene (Uniprot):TGME49_285990
Chain IDs:ZA (auth: HA), AB (auth: HB), BB (auth: HC), CB (auth: HD)
Chain Length:1192
Number of Molecules:4
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR12, TGME49_292170
Gene (Uniprot):TGME49_292170
Chain IDs:DB (auth: IA), EB (auth: IB), FB (auth: IC)
Chain Length:1599
Number of Molecules:3
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR10, TGME49_298010
Gene (Uniprot):TGME49_298010
Chain IDs:GB (auth: JA), HB (auth: JB), IB (auth: JC)
Chain Length:2316
Number of Molecules:3
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR14, TGME49_311880
Gene (Uniprot):TGME49_311880
Chain IDs:JB (auth: KA), KB, LB (auth: KC), MB (auth: KE), NB (auth: KF), OB (auth: KG)
Chain Length:728
Number of Molecules:6
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ICAP16, TGME49_202120
Gene (Uniprot):TGME49_202120
Chain IDs:PB (auth: LA), QB (auth: LB), RB (auth: LC), SB (auth: LD), TB (auth: LE), UB (auth: LF), VB (auth: LG), WB (auth: LH), XB (auth: LI), YB (auth: LJ), ZB (auth: LK), AC (auth: LL), BC (auth: LM), CC (auth: LN), DC (auth: LO), EC (auth: LP)
Chain Length:1322
Number of Molecules:16
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR12, TGME49_219070
Gene (Uniprot):TGME49_219070
Chain IDs:FC (auth: MA), GC (auth: MB), HC (auth: MC), IC (auth: MD), JC (auth: ME), KC (auth: MF), LC (auth: MG), MC (auth: MH), NC (auth: MI), OC (auth: MJ), PC (auth: MK), QC (auth: ML)
Chain Length:2736
Number of Molecules:12
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:myosin L, TGME49_291020
Gene (Uniprot):TGME49_291020
Chain IDs:RC (auth: NA), SC (auth: NB), TC (auth: NC), UC (auth: ND)
Chain Length:2484
Number of Molecules:4
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR13, TGME49_284620
Gene (Uniprot):TGME49_284620
Chain IDs:VC (auth: OA), WC (auth: OB), XC (auth: OC)
Chain Length:2333
Number of Molecules:3
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:PCR15, TGME49_232560
Gene (Uniprot):TGME49_232560
Chain IDs:YC (auth: PA), ZC (auth: PB), AD (auth: PC)
Chain Length:1822
Number of Molecules:3
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:MLC4, TGME49_294390
Gene (Uniprot):TGRH88_019480
Chain IDs:BD (auth: QA), CD (auth: QB), DD (auth: QC), ED (auth: QD)
Chain Length:172
Number of Molecules:4
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Calmodulin
Gene (Uniprot):TGRH88_061130
Chain IDs:FD (auth: RA), GD (auth: RB), HD (auth: RC), ID (auth: RD)
Chain Length:179
Number of Molecules:4
Biological Source:Toxoplasma gondii
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Calmodulin
Gene (Uniprot):TGRH88_062970
Chain IDs:JD (auth: SA), KD (auth: SB), LD (auth: SC), MD (auth: SD)
Chain Length:149
Number of Molecules:4
Biological Source:Toxoplasma gondii
Ligand Molecules
Primary Citation
Atomic models of the Toxoplasma cell invasion machinery.
Nat.Struct.Mol.Biol. ? ? ? (2025)
PMID: 41366525 DOI: 10.1038/s41594-025-01728-w

Abstact

Apicomplexan parasites, responsible for toxoplasmosis, cryptosporidiosis and malaria, invade host cells through a unique gliding motility mechanism powered by actomyosin motors and a dynamic organelle called the conoid. Here, using cryo-electron microscopy, we determined structures of four essential complexes of the Toxoplasma gondii conoid: the preconoidal P2 ring, tubulin-based conoid fibers, and the subpellicular and intraconoidal microtubules. Our analysis identified 40 distinct conoid proteins, several of which are essential for parasite lytic growth, as revealed through genetic disruption studies. Comparative analysis of the tubulin-containing complexes sheds light on their functional specialization by microtubule-associated proteins, while the structure of the preconoidal ring pinpoints the site of actin polymerization and initial translocation, enhancing our mechanistic understanding of gliding motility and, therefore, parasite invasion.
