9WH8 image
Deposition Date 2025-08-26
Release Date 2026-03-04
Last Version Date 2026-03-04
Entry Detail
PDB ID:
9WH8
Keywords:
SIGNALING PROTEIN
Title:
Crystal Structure of Human STING bound to diABZI3
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.90 Å
R-Value Free:
0.26
R-Value Work:
0.20
R-Value Observed:
0.21
Space Group:
P 61 2 2
9WH8 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Stimulator of interferon genes protein
Gene (Uniprot):STING1
Chain IDs:A (auth: B)
Chain Length:188
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q86WV6 Pfam ID:PF15009
Ligand Molecules
A1AZ0
Primary Citation
Species-Specific Regulation of STING by a C195 Disulfide Tetramer in Duck
To Be Published ? ? ? (?)
Primary Citation of related structures
9WH8
