9V52 image
Deposition Date 2025-05-25
Release Date 2025-11-05
Last Version Date 2025-12-31
Entry Detail
PDB ID:
9V52
Keywords:
PROTEIN TRANSPORT
Title:
Structure of TolC and YbjP closed state complex
Biological Source:
Source Organism:
Escherichia coli (strain K12) (Taxon ID: 83333)
Host Organism:
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.56 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9V52 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Outer membrane protein TolC
Gene (Uniprot):tolC
Chain IDs:A (auth: C1), C (auth: C3), E (auth: C2)
Chain Length:493
Number of Molecules:3
Biological Source:Escherichia coli (strain K12)
UniProt ID:P02930 Pfam ID:PF02321
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Uncharacterized lipoprotein YbjP
Gene (Uniprot):ybjP
Chain IDs:B (auth: P1), D (auth: P3), F (auth: P2)
Chain Length:171
Number of Molecules:3
Biological Source:Escherichia coli (strain K12)
UniProt ID:P75818 Pfam ID:PF12883
Ligand Molecules
NA
Primary Citation
Structural mechanisms of pump assembly and drug transport in the AcrAB-TolC efflux system
Elife ? ? ? (2025)
DOI: 10.7554/elife.109684.1
