9RPD image
Deposition Date 2025-06-24
Release Date 2025-08-27
Last Version Date 2025-08-27
Entry Detail
PDB ID:
9RPD
Keywords:
CELL CYCLE
Title:
D. melanogaster Augmin TII N-clamp (GST-fusion) bound to a microtubule, well-defined subset of particles
Biological Source:
Source Organism:
Drosophila melanogaster (Taxon ID: 7227)
Aequorea victoria (Taxon ID: 6100)
Schistosoma japonicum (Taxon ID: 6182)
Sus scrofa (Taxon ID: 9823)
Host Organism:
Escherichia coli
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
4.90 Å
Aggregation State:
HELICAL ARRAY
Reconstruction Method:
SINGLE PARTICLE
9RPD validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tubulin alpha-1A chain
Gene (Uniprot):TUBA1A
Chain IDs:F (auth: A), G (auth: C), H (auth: G), I (auth: E)
Chain Length:451
Number of Molecules:4
Biological Source:Sus scrofa
UniProt ID:P02550 Pfam ID:PF00091, PF03953
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tubulin beta chain
Chain IDs:D (auth: B), E (auth: D)
Chain Length:445
Number of Molecules:2
Biological Source:Sus scrofa
UniProt ID:P02554 Pfam ID:PF00091, PF03953
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Augmin complex subunit dgt4
Gene (Uniprot):dgt4
Chain IDs:A (auth: I)
Chain Length:108
Number of Molecules:1
Biological Source:Drosophila melanogaster
UniProt ID:Q9W4M8
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Augmin complex subunit dgt6
Gene (Uniprot):dgt6
Chain IDs:B (auth: J)
Chain Length:280
Number of Molecules:1
Biological Source:Drosophila melanogaster
UniProt ID:Q9VAP2 Pfam ID:PF14661
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Augmin complex subunit msd5,Green fluorescent protein,Glutathione S-transferase class-mu 26 kDa isozyme
Gene (Uniprot):GFP, msd5
Chain IDs:C (auth: K)
Chain Length:672
Number of Molecules:1
Biological Source:Drosophila melanogaster, Aequorea victoria, Schistosoma japonicum
UniProt ID:Q9W0G6,P42212,P08515 Pfam ID:PF01353, PF02798, PF14497 EC:2.5.1.18
Ligand Molecules
NA
Primary Citation
Structural insights into the augmin-microtubule interaction reveal a conserved function of the HAUS6 CH domain in orienting augmin on microtubules
To Be Published ? ? ? (2025)
DOI: 10.1038/s41467-025-63165-z
Primary Citation of related structures
9RPD
