9RK8 image
Deposition Date 2025-06-13
Release Date 2025-11-12
Last Version Date 2025-11-26
Entry Detail
PDB ID:
9RK8
Keywords:
Title:
Crystal Structure of compound 3-mediated ternary complex of KRAS G12V C118S GDP with pVHL:ElonginC:ElonginB
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.63 Å
R-Value Free:
0.26
R-Value Work:
0.23
R-Value Observed:
0.23
Space Group:
C 2 2 21
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Elongin-B
Gene (Uniprot):ELOB
Chain IDs:A, E
Chain Length:104
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Elongin-C
Gene (Uniprot):ELOC
Chain IDs:B, F
Chain Length:97
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:von Hippel-Lindau disease tumor suppressor
Gene (Uniprot):VHL
Chain IDs:C, G
Chain Length:162
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:GTPase KRas
Gene (Uniprot):KRAS
Chain IDs:D, H
Chain Length:170
Number of Molecules:2
Biological Source:Homo sapiens
Primary Citation
Identification of a Highly Cooperative PROTAC Degrader Targeting GTP-Loaded KRAS(On) Alleles.
J.Am.Chem.Soc. 147 41367 41378 (2025)
PMID: 41166656 DOI: 10.1021/jacs.5c10354

Abstact

Kirsten rat sarcoma viral oncogene homologue (KRAS) is a frequently mutated oncogene in multiple types of cancer and is a high priority target for oncology drug development. There are many different KRAS mutations, including mutations that favor the GTP-loaded hydrolysis-incompetent "active" state of KRAS, KRAS(on), that can lead to tumorigenesis. However, small molecule interventions thus far have predominantly targeted single mutations of "inactive" GDP-loaded KRAS, KRAS(off), such as KRASG12C. Here, we address this gap through the development of heterobifunctional VHL-based PROTACs capable of engaging and degrading KRAS(on), thus addressing a wider range of KRAS mutations. By studying ternary complex affinity, stability, and binding modes using SPR and X-ray cocrystal structures, we identified PROTACs that exhibit high positive cooperativity in forming ternary complexes with VHL and GCP-loaded KRAS as representative of KRAS(on) variants. Degrader activity profiling in relevant cancer cells supported the discovery of ACBI4, a PROTAC which forms a highly stable and cooperative ternary complex between VHL and GTP-bound KRAS and which potently degrades KRASG12R, leading to antiproliferative effect in KRAS mutant-driven cancer cells. ACBI4 provides a new chemical tool for studying the impact of degrading KRAS(on) mutants, which is not possible with current pan-KRAS inhibitors or degraders.
