9PY3 image
Deposition Date 2025-08-06
Release Date 2025-11-12
Last Version Date 2025-11-12
Entry Detail
PDB ID:
9PY3
Keywords:
MEMBRANE PROTEIN
Title:
Unlatched-state loperamide-mu opioid receptor-Gi GDPbS complex (rebound)
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Spodoptera frugiperda
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.20 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9PY3 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(i) subunit alpha-1
Gene (Uniprot):GNAI1
Chain IDs:D (auth: A)
Chain Length:354
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63096 Pfam ID:PF00503
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1
Gene (Uniprot):GNB1
Chain IDs:A (auth: B)
Chain Length:361
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62873 Pfam ID:PF00400
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2
Gene (Uniprot):GNG2
Chain IDs:B (auth: C)
Chain Length:71
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P59768 Pfam ID:PF00631
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Soluble cytochrome b562,Mu-type opioid receptor
Gene (Uniprot):cybC, OPRM1
Chain IDs:C (auth: R)
Chain Length:622
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P0ABE7,P35372 Pfam ID:PF07361, PF00001
Ligand Molecules
A1CMV
CLR
VSN
Primary Citation
Ligand efficacy is driven by conformational control of nucleotide exchange at the mu opioid receptor.
To Be Published ? ? ? (?)
Primary Citation of related structures
9PY3
