9PJD image
Deposition Date 2025-07-13
Release Date 2025-11-12
Last Version Date 2025-11-12
Entry Detail
PDB ID:
9PJD
Keywords:
CHAPERONE
Title:
Cryo-EM structure of the ClpXP AAA+ protease bound to an unidentified portion of lambdaO-tagged Arc substrate within a translocation complex
Biological Source:
Source Organism:
Escherichia coli (Taxon ID: 562)
Host Organism:
Escherichia coli BL21(DE3)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.67 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9PJD validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP-dependent Clp protease ATP-binding subunit ClpX
Gene (Uniprot):clpX
Chain IDs:A, B, C, D, E, F
Chain Length:424
Number of Molecules:6
Biological Source:Escherichia coli
UniProt ID:C3TLS7 Pfam ID:PF06689, PF07724, PF10431
Polymer Type:polyribonucleotide
Molecule:unidentified portion of the substrate
Chain IDs:G
Chain Length:6
Number of Molecules:1
Biological Source:Escherichia coli
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:ATP-dependent Clp protease proteolytic subunit
Gene (Uniprot):clpP
Chain IDs:H, I, J, K, L, M, N, O, P, Q, R, S, T, U
Chain Length:207
Number of Molecules:14
Biological Source:Escherichia coli
UniProt ID:P0A6G7 Pfam ID:PF00574 EC:3.4.21.92
Ligand Molecules
AGS
MG
Primary Citation
Cryo-EM structure of the ClpXP AAA+ protease bound to an unidentified portion of lambdaO-tagged Arc within a translocation complex
To Be Published ? ? ? (?)
Primary Citation of related structures
9PJD
