ISDA: 9P92

Deposition Date 2025-06-24

Release Date 2025-11-19

Last Version Date 2025-11-19

Entry Detail

PDB ID:

9P92

Keywords:

MEMBRANE PROTEIN

Title:

Cryo-EM structure of the PAC1nR-VIP-Gs complex

Biological Source:

Source Organism:

Homo sapiens (Taxon ID: 9606)
Lama glama (Taxon ID: 9844)

Host Organism:

Trichoplusia ni

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.80 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(s) subunit alpha isoforms short
Gene (Uniprot):GNAS
Mutagens:S54N, G226A, E268A, N271K, K274D, R280K, T284D, I285T , A366S
Chain IDs:A
Chain Length:394
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P63092 Pfam ID:PF00503

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1
Gene (Uniprot):GNB1
Chain IDs:B
Chain Length:350
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P62873 Pfam ID:PF00400

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2
Gene (Uniprot):GNG2
Chain IDs:C (auth: G)
Chain Length:71
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P59768 Pfam ID:PF00631

Polymer Type:polypeptide(L)
Molecule:Nanobody35
Chain IDs:D (auth: N)
Chain Length:138
Number of Molecules:1
Biological Source:Lama glama

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Vasoactive intestinal peptide
Gene (Uniprot):VIP
Chain IDs:F (auth: P)
Chain Length:28
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P01282 Pfam ID:PF00123

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Pituitary adenylate cyclase-activating polypeptide type I receptor
Gene (Uniprot):ADCYAP1R1
Chain IDs:E (auth: R)
Chain Length:483
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P41586 Pfam ID:PF02793, PF00002

Ligand Molecules

Primary Citation

Structural basis of modified ligand selectivity from N-terminal PAC1R alternative splicing.

Lu, J, Sexton, P, Wootten, D, Piper, S.J.Show

To Be Published ? ? ? (?)
