9P7H image
Deposition Date 2025-06-20
Release Date 2025-12-24
Last Version Date 2025-12-24
Entry Detail
PDB ID:
9P7H
Keywords:
RIBOSOME
Title:
In situ HHT and CHX treated human eEF1A-A/T-P state 80S ribosome
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.68 Å
Aggregation State:
CELL
Reconstruction Method:
SINGLE PARTICLE
9P7H validation report
Macromolecular Entities
Polymer Type:polyribonucleotide
Molecule:A/T site tRNA [Homo sapiens]
Chain IDs:C (auth: AT)
Chain Length:76
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Elongation factor 1-alpha 1
Gene (Uniprot):EEF1A1
Chain IDs:B (auth: CF)
Chain Length:441
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P68104 Pfam ID:PF00009, PF03144, PF22594
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Transcription factor BTF3
Gene (Uniprot):BTF3
Chain IDs:GC (auth: CI)
Chain Length:31
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P20290
Polymer Type:polyribonucleotide
Molecule:28S rRNA [Homo sapiens]
Chain IDs:D (auth: L5)
Chain Length:3655
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:5S rRNA [Homo sapiens]
Chain IDs:E (auth: L7)
Chain Length:120
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:5.8S rRNA [Homo sapiens]
Chain IDs:F (auth: L8)
Chain Length:156
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L8
Gene (Uniprot):RPL8
Chain IDs:G (auth: LA)
Chain Length:147
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62917 Pfam ID:PF00181, PF03947
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein uL3
Gene (Uniprot):RPL3
Chain IDs:H (auth: LB)
Chain Length:402
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P39023 Pfam ID:PF00297
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L4
Gene (Uniprot):RPL4
Chain IDs:I (auth: LC)
Chain Length:98
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P36578 Pfam ID:PF00573, PF14374
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein uL18
Gene (Uniprot):RPL5
Chain IDs:J (auth: LD)
Chain Length:293
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46777 Pfam ID:PF17144, PF14204
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein eL6
Gene (Uniprot):RPL6
Chain IDs:K (auth: LE)
Chain Length:250
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q02878 Pfam ID:PF03868, PF01159
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L7
Gene (Uniprot):RPL7
Chain IDs:L (auth: LF)
Chain Length:225
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P18124 Pfam ID:PF08079, PF00327
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L7a
Gene (Uniprot):RPL7A
Chain IDs:M (auth: LG)
Chain Length:114
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62424 Pfam ID:PF01248
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L9
Gene (Uniprot):RPL9, RPL9P7, RPL9P8, RPL9P9
Chain IDs:N (auth: LH)
Chain Length:190
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P32969 Pfam ID:PF00347
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ribosomal protein uL16-like
Gene (Uniprot):RPL10L
Chain IDs:O (auth: LI)
Chain Length:213
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q96L21 Pfam ID:PF00252
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L11
Gene (Uniprot):RPL11
Chain IDs:P (auth: LJ)
Chain Length:86
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62913 Pfam ID:PF00281, PF00673
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein eL13
Gene (Uniprot):RPL13
Chain IDs:Q (auth: LL)
Chain Length:50
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P26373 Pfam ID:PF01294
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L14
Gene (Uniprot):RPL14
Chain IDs:R (auth: LM)
Chain Length:52
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P50914 Pfam ID:PF01929
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L15
Gene (Uniprot):RPL15
Chain IDs:S (auth: LN)
Chain Length:24
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61313 Pfam ID:PF00827
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L13a
Gene (Uniprot):RPL13A
Chain IDs:T (auth: LO)
Chain Length:201
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P40429 Pfam ID:PF00572
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L17
Gene (Uniprot):RPL17
Chain IDs:U (auth: LP)
Chain Length:153
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P18621 Pfam ID:PF00237
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L18
Gene (Uniprot):RPL18
Chain IDs:V (auth: LQ)
Chain Length:187
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q07020 Pfam ID:PF17135
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L19
Gene (Uniprot):RPL19
Chain IDs:W (auth: LR)
Chain Length:187
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P84098 Pfam ID:PF01280
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L18a
Gene (Uniprot):RPL18A
Chain IDs:X (auth: LS)
Chain Length:175
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q02543 Pfam ID:PF01775
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L21
Gene (Uniprot):RPL21
Chain IDs:Y (auth: LT)
Chain Length:157
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46778 Pfam ID:PF01157
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Heparin-binding protein HBp15
Chain IDs:Z (auth: LU)
Chain Length:101
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q7Z4W8 Pfam ID:PF01776
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L23
Gene (Uniprot):RPL23
Chain IDs:AA (auth: LV)
Chain Length:131
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62829 Pfam ID:PF00238
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ribosomal protein L24
Gene (Uniprot):RPL24
Chain IDs:BA (auth: LW)
Chain Length:124
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:A0A994J4A5 Pfam ID:PF01246
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L23a
Gene (Uniprot):RPL23A
Chain IDs:CA (auth: LX)
Chain Length:120
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62750 Pfam ID:PF03939, PF00276
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L26
Gene (Uniprot):RPL26
Chain IDs:DA (auth: LY)
Chain Length:134
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61254 Pfam ID:PF16906, PF00467
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L27
Gene (Uniprot):RPL27
Chain IDs:EA (auth: LZ)
Chain Length:135
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61353 Pfam ID:PF00467, PF01777
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L27a
Gene (Uniprot):RPL27A
Chain IDs:FA (auth: La)
Chain Length:147
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46776 Pfam ID:PF00828
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein eL29
Gene (Uniprot):RPL29
Chain IDs:GA (auth: Lb)
Chain Length:402
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P47914 Pfam ID:PF01779
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L30
Gene (Uniprot):RPL30
Chain IDs:HA (auth: Lc)
Chain Length:98
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62888 Pfam ID:PF01248
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L31
Gene (Uniprot):RPL31
Chain IDs:IA (auth: Ld)
Chain Length:293
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62899 Pfam ID:PF01198
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L32
Gene (Uniprot):RPL32
Chain IDs:JA (auth: Le)
Chain Length:250
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62910 Pfam ID:PF01655
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L35a
Gene (Uniprot):RPL35A
Chain IDs:KA (auth: Lf)
Chain Length:225
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P18077 Pfam ID:PF01247
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L34
Gene (Uniprot):RPL34
Chain IDs:LA (auth: Lg)
Chain Length:114
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P49207 Pfam ID:PF01199
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L35
Gene (Uniprot):RPL35
Chain IDs:MA (auth: Lh)
Chain Length:190
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P42766 Pfam ID:PF00831
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L36
Gene (Uniprot):RPL36
Chain IDs:NA (auth: Li)
Chain Length:213
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q9Y3U8 Pfam ID:PF01158
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L37
Gene (Uniprot):RPL37
Chain IDs:OA (auth: Lj)
Chain Length:86
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61927 Pfam ID:PF01907
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L38
Gene (Uniprot):RPL38
Chain IDs:PA (auth: Lk)
Chain Length:69
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63173 Pfam ID:PF01781
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L39
Gene (Uniprot):RPL39
Chain IDs:QA (auth: Ll)
Chain Length:50
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62891 Pfam ID:PF00832
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein eL40
Gene (Uniprot):UBA52
Chain IDs:RA (auth: Lm)
Chain Length:52
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62987 Pfam ID:PF01020
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L41
Gene (Uniprot):RPL41
Chain IDs:SA (auth: Ln)
Chain Length:24
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62945 Pfam ID:PF05162
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L36a
Gene (Uniprot):RPL36A
Chain IDs:TA (auth: Lo)
Chain Length:201
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P83881 Pfam ID:PF00935
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L37a
Gene (Uniprot):RPL37A
Chain IDs:UA (auth: Lp)
Chain Length:153
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61513 Pfam ID:PF01780
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L28
Gene (Uniprot):RPL28
Chain IDs:VA (auth: Lr)
Chain Length:187
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46779 Pfam ID:PF01778
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S acidic ribosomal protein P0
Gene (Uniprot):RPLP0
Chain IDs:WA (auth: Ls)
Chain Length:175
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P05388 Pfam ID:PF00466, PF17777
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein uL11
Gene (Uniprot):RPL12
Chain IDs:XA (auth: Lt)
Chain Length:157
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P30050 Pfam ID:PF03946, PF00298
Polymer Type:polyribonucleotide
Molecule:P site tRNA [Homo sapiens]
Chain IDs:A (auth: Pt)
Chain Length:74
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:18S rRNA [Homo sapiens]
Chain IDs:FC (auth: S2)
Chain Length:1740
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein SA
Gene (Uniprot):RPSA
Chain IDs:NB (auth: SA)
Chain Length:102
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P08865 Pfam ID:PF00318
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S3a
Gene (Uniprot):RPS3A
Chain IDs:OB (auth: SB)
Chain Length:214
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61247 Pfam ID:PF01015
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S2
Gene (Uniprot):RPS2
Chain IDs:PB (auth: SC)
Chain Length:222
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P15880 Pfam ID:PF00333, PF03719
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein uS3
Gene (Uniprot):RPS3
Chain IDs:YA (auth: SD)
Chain Length:227
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P23396 Pfam ID:PF07650, PF00189
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS4, X isoform
Gene (Uniprot):RPS4X
Chain IDs:QB (auth: SE)
Chain Length:262
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62701 Pfam ID:PF08071, PF00900, PF00467, PF16121
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S5
Gene (Uniprot):RPS5
Chain IDs:ZA (auth: SF)
Chain Length:67
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46782 Pfam ID:PF00177
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S6
Gene (Uniprot):RPS6
Chain IDs:RB (auth: SG)
Chain Length:237
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62753 Pfam ID:PF01092
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS7
Gene (Uniprot):RPS7
Chain IDs:SB (auth: SH)
Chain Length:189
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62081 Pfam ID:PF01251
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S8
Gene (Uniprot):RPS8
Chain IDs:TB (auth: SI)
Chain Length:206
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62241 Pfam ID:PF01201
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S9
Gene (Uniprot):RPS9
Chain IDs:UB (auth: SJ)
Chain Length:185
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46781 Pfam ID:PF00163, PF01479
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S10
Gene (Uniprot):RPS10
Chain IDs:AB (auth: SK)
Chain Length:98
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46783 Pfam ID:PF03501
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S11
Gene (Uniprot):RPS11
Chain IDs:VB (auth: SL)
Chain Length:153
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62280 Pfam ID:PF16205, PF00366
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS12
Gene (Uniprot):RPS12
Chain IDs:BB (auth: SM)
Chain Length:122
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P25398 Pfam ID:PF01248
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S13
Gene (Uniprot):RPS13
Chain IDs:WB (auth: SN)
Chain Length:150
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62277 Pfam ID:PF08069, PF00312
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein uS11
Gene (Uniprot):RPS14
Chain IDs:XB (auth: SO)
Chain Length:140
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62263 Pfam ID:PF00411
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein uS19
Gene (Uniprot):RPS15
Chain IDs:CB (auth: SP)
Chain Length:121
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62841 Pfam ID:PF00203
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein uS9
Gene (Uniprot):RPS16
Chain IDs:DB (auth: SQ)
Chain Length:144
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62249 Pfam ID:PF00380
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS17
Gene (Uniprot):RPS17
Chain IDs:EB (auth: SR)
Chain Length:135
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P08708 Pfam ID:PF00833
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S18
Gene (Uniprot):RPS18
Chain IDs:FB (auth: SS)
Chain Length:145
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62269 Pfam ID:PF00416
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S19
Gene (Uniprot):RPS19
Chain IDs:GB (auth: ST)
Chain Length:143
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P39019 Pfam ID:PF01090
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S20
Gene (Uniprot):RPS20
Chain IDs:HB (auth: SU)
Chain Length:104
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P60866 Pfam ID:PF00338
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS21
Gene (Uniprot):RPS21
Chain IDs:YB (auth: SV)
Chain Length:83
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63220 Pfam ID:PF01249
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S15a
Gene (Uniprot):RPS15A
Chain IDs:ZB (auth: SW)
Chain Length:129
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62244 Pfam ID:PF00410
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S23
Gene (Uniprot):RPS23
Chain IDs:AC (auth: SX)
Chain Length:141
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62266 Pfam ID:PF00164
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S24
Gene (Uniprot):RPS24
Chain IDs:BC (auth: SY)
Chain Length:131
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62847 Pfam ID:PF01282
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS25
Gene (Uniprot):RPS25
Chain IDs:IB (auth: SZ)
Chain Length:75
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62851 Pfam ID:PF03297
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S26
Gene (Uniprot):RPS26
Chain IDs:CC (auth: Sa)
Chain Length:102
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62854 Pfam ID:PF01283
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS27
Gene (Uniprot):RPS27
Chain IDs:DC (auth: Sb)
Chain Length:214
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P42677 Pfam ID:PF01667
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S28
Gene (Uniprot):RPS28
Chain IDs:JB (auth: Sc)
Chain Length:222
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62857 Pfam ID:PF01200
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S29
Gene (Uniprot):RPS29
Chain IDs:KB (auth: Sd)
Chain Length:227
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62273 Pfam ID:PF00253
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein eS30
Gene (Uniprot):FAU
Chain IDs:EC (auth: Se)
Chain Length:262
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62861 Pfam ID:PF04758
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ubiquitin-40S ribosomal protein S27a
Gene (Uniprot):RPS27A
Chain IDs:LB (auth: Sf)
Chain Length:67
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62979 Pfam ID:PF01599
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Receptor of activated protein C kinase 1
Gene (Uniprot):RACK1
Chain IDs:MB (auth: Sg)
Chain Length:237
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63244 Pfam ID:PF00400
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
OMG F G modified residue
PSU F U modified residue
SEP B SER modified residue
Ligand Molecules
3HE
HMT
MG
SPD
SPM
ZN
Primary Citation
Visualizing the translation landscape in human cells at high resolution.
Nat Commun 16 10757 10757 (2025)
PMID: 41315256 DOI: 10.1038/s41467-025-65795-9

Abstact

Comprehensive in situ structures of macromolecules can transform our understanding of biology and advance human health. Here, we map protein synthesis inside human cells in detail by combining automated cryo-focused ion beam (FIB) milling and in situ single-particle cryo electron microscopy (cryo-EM). With this in situ cryo-EM approach, we resolved a 2.2 Å consensus structure of the human 80S ribosome and unveiled 23 functional states, nearly all better than 3 Å resolution. Compared to in vitro studies, we observed variations in ribosome structures, distinct environments of ion and polyamine binding, and associated proteins such as EDF1 and NACβ that are typically not enriched with purified ribosomes. We also detected additional peptide-related density features on the ribosome and visualized ribosome-ribosome interactions in helical polysomes. Finally, high-resolution structures from cells treated with homoharringtonine and cycloheximide revealed a distinct translational landscape and a spermidine that interacts with cycloheximide at the E site, one of the numerous polyamines that also bind native ribosomes. These results underscore the value of high-resolution in situ studies in the native environment.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
9P7H
Feedback Form
Name
Email
Institute
Feedback
