9OCH image
Deposition Date 2025-04-24
Release Date 2025-09-10
Last Version Date 2025-09-10
Entry Detail
PDB ID:
9OCH
Keywords:
MEMBRANE PROTEIN
Title:
Transporter associated with antigen processing (TAP) bound to the viral protein hUS6 in the outward-facing open state
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Human betaherpesvirus 5 (Taxon ID: 10359)
Host Organism:
Homo sapiens
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.30 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9OCH validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Antigen peptide transporter 1
Gene (Uniprot):TAP1
Chain IDs:C (auth: A)
Chain Length:887
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q03518 Pfam ID:PF00664, PF00005 EC:7.4.2.14
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Antigen peptide transporter 2
Gene (Uniprot):TAP2
Chain IDs:A (auth: B)
Chain Length:686
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q03519 Pfam ID:PF00664, PF00005 EC:7.4.2.14
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:TAP transport inhibitor US6
Gene (Uniprot):US6
Chain IDs:B (auth: D)
Chain Length:239
Number of Molecules:1
Biological Source:Human betaherpesvirus 5
UniProt ID:P14334 Pfam ID:PF17616
Ligand Molecules
ADP
ATP
MG
Primary Citation
Transporter associated with antigen processing (TAP) bound to the viral protein US6 in the outward-facing open state
To Be Published ? ? ? (?)
Primary Citation of related structures
9OCH
