9O5S image
Deposition Date 2025-04-10
Release Date 2025-07-23
Last Version Date 2025-08-06
Entry Detail
PDB ID:
9O5S
Keywords:
Title:
minibinder-antigen complex BXMart1-3-MART1-HLA*A02
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.27 Å
R-Value Free:
0.23
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:HLA class I histocompatibility antigen, A alpha chain
Gene (Uniprot):HLA-A
Chain IDs:A, F (auth: C), G (auth: H), H (auth: L)
Chain Length:279
Number of Molecules:4
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Beta-2-microglobulin
Gene (Uniprot):B2M
Chain IDs:B, I (auth: D), J (auth: I), K (auth: M)
Chain Length:99
Number of Molecules:4
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:antibody AD01
Chain IDs:D (auth: G), O (auth: F), P (auth: K), Q (auth: O)
Chain Length:117
Number of Molecules:4
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Melanoma antigen recognized by T-cells 1
Gene (Uniprot):MLANA
Chain IDs:C (auth: P), L (auth: E), M (auth: J), N
Chain Length:10
Number of Molecules:4
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:BXMart1-3 minibinder
Chain IDs:E (auth: Q), R, S, T
Chain Length:102
Number of Molecules:4
Biological Source:synthetic construct
Ligand Molecules
Primary Citation
Design of high-specificity binders for peptide-MHC-I complexes.
Science 389 386 391 (2025)
PMID: 40705892 DOI: 10.1126/science.adv0185

Abstact

Class I major histocompatibility complex (MHC-I) molecules present peptides derived from intracellular antigens on the cell surface for immune surveillance. Proteins that recognize peptide-MHC-I (pMHCI) complexes with specificity for diseased cells could have considerable therapeutic utility. Specificity requires recognition of outward-facing amino acid residues within the disease-associated peptide as well as avoidance of extensive contacts with ubiquitously expressed MHC. We used RFdiffusion to design pMHCI-binding proteins that make extensive contacts with the peptide and identified specific binders for 11 target pMHCs starting from either experimental or predicted pMHCI structures. Upon incorporation into chimeric antigen receptors, designs for eight targets conferred peptide-specific T cell activation. Our approach should have broad utility for both protein- and cell-based pMHCI targeting.
