9O04 image
Deposition Date 2025-04-02
Release Date 2026-01-21
Last Version Date 2026-01-21
Entry Detail
PDB ID:
9O04
Keywords:
TRANSFERASE
Title:
CryoEM structure of the FBXO42-CCDC6-PP2Ac degradasome
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Expression System(s):
Trichoplusia ni
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.20 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9O04 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Coiled-coil domain-containing protein 6
Gene (Uniprot):CCDC6
Chain IDs:A, B
Chain Length:490
Number of Molecules:2
Biological Source:Homo sapiens
UniProt ID:Q16204 Pfam ID:PF09755
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:F-box only protein 42
Gene (Uniprot):FBXO42
Chain IDs:C, G
Chain Length:691
Number of Molecules:2
Biological Source:Homo sapiens
UniProt ID:Q6P3S6 Pfam ID:PF12937, PF13415
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Serine/threonine-protein phosphatase 2A catalytic subunit alpha isoform
Gene (Uniprot):PPP2CA
Chain IDs:D, E, I, J, K, L, M, N
Chain Length:336
Number of Molecules:8
Biological Source:Homo sapiens
UniProt ID:P67775 Pfam ID:PF00149 EC:3.1.3.16
Polymer Type:polypeptide(L)
Molecule:SKP1
Chain IDs:F, H
Chain Length:151
Number of Molecules:2
Biological Source:Homo sapiens
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
MLL D LEU modified residue
Ligand Molecules
MN
Primary Citation
The SCFFBXO42-CCDC6 axis regulates proteosomal degradation of the catalytic subunit of PP2A
To Be Published ? ? ? (?)
