9N65 image
Deposition Date 2025-02-04
Release Date 2025-09-03
Last Version Date 2025-09-03
Entry Detail
PDB ID:
9N65
Keywords:
MEMBRANE PROTEIN
Title:
Transporter associated with antigen processing (TAP) bound to ATP and ADP In the inward-facing conformation
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Homo sapiens
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.00 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9N65 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Antigen peptide transporter 1
Gene (Uniprot):TAP1
Chain IDs:A
Chain Length:748
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q03518 Pfam ID:PF00664, PF00005 EC:7.4.2.14
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Antigen peptide transporter 2
Gene (Uniprot):TAP2
Chain IDs:B
Chain Length:686
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q03519 Pfam ID:PF00664, PF00005 EC:7.4.2.14
Ligand Molecules
ADP
ATP
MG
Primary Citation
Transporter associated with antigen processing (TAP) bound to ATP and ADP In the inward-facing conformation
To Be Published ? ? ? (?)
Primary Citation of related structures
9N65
