ISDA: 9MOH

Deposition Date 2024-12-26

Release Date 2026-01-28

Last Version Date 2026-01-28

Entry Detail

PDB ID:

9MOH

Keywords:

VIRAL PROTEIN

Title:

Structure of the middle part of the bacteriophage T4 tail

Biological Source:

Source Organism(s):

Escherichia phage T4 (Taxon ID: 2681598)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.40 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:gp18, tail sheath protein
Chain IDs:A (auth: K0), B (auth: K1), C (auth: K2), D (auth: K3), E (auth: K4), F (auth: K5), G (auth: K6), H (auth: K7), I (auth: K8), J (auth: K9), K (auth: L0), L (auth: L1), M (auth: L2), N (auth: L3), O (auth: L4), P (auth: L5), Q (auth: L6), R (auth: L7), S (auth: L8), T (auth: L9), U (auth: LQ), V (auth: LR), W (auth: LS), X (auth: LU), Y (auth: LV), Z (auth: LW), AA (auth: LX), BA (auth: LY), CA (auth: LZ), DA (auth: La), EA (auth: Lb), FA (auth: Lc), GA (auth: Ld), HA (auth: Le), IA (auth: Lv), JA (auth: Lw), KA (auth: Lx), LA (auth: Lz), MA (auth: M0), NA (auth: M1), OA (auth: M2), PA (auth: M3), QA (auth: M4), RA (auth: M5), SA (auth: M6), TA (auth: M7), UA (auth: M8), VA (auth: M9), WA (auth: MQ), XA (auth: MR), YA (auth: MS), ZA (auth: MU), AB (auth: MV), BB (auth: MW), CB (auth: MX), DB (auth: MY), EB (auth: MZ), FB (auth: Ma), GB (auth: Mb), HB (auth: Mc), IB (auth: Md), JB (auth: Me), KB (auth: Mv), LB (auth: Mw), MB (auth: Mx), NB (auth: Mz), OB (auth: NV), PB (auth: NW), QB (auth: NX), RB (auth: NZ), SB (auth: Na), TB (auth: Nb), UB (auth: Nc), VB (auth: Nd), WB (auth: Ne), XB (auth: Nf), YB (auth: Ng), ZB (auth: Nh), AC (auth: Ni), BC (auth: Nj), CC (auth: Nv), DC (auth: Nw), EC (auth: Nx), FC (auth: Nz)
Chain Length:659
Number of Molecules:84
Biological Source:Escherichia phage T4

UniProt ID:A0A7S9SVW9

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:gp19, tail tube protein
Chain IDs:GC (auth: OC), HC (auth: OD), IC (auth: OE), JC (auth: OF), KC (auth: OG), LC (auth: OH), MC (auth: OI), NC (auth: OJ), OC (auth: OK), PC (auth: OL), QC (auth: OM), RC (auth: ON), SC (auth: OO), TC (auth: Oh), UC (auth: Oi), VC (auth: Oj), WC (auth: Ok), XC (auth: Ol), YC (auth: Om), ZC (auth: On), AD (auth: Oo), BD (auth: Op), CD (auth: Oq), DD (auth: Or), ED (auth: Os), FD (auth: Ot), GD (auth: PC), HD (auth: PD), ID (auth: PE), JD (auth: PF), KD (auth: PG), LD (auth: PH), MD (auth: PI), ND (auth: PJ), OD (auth: PK), PD (auth: PL), QD (auth: PM), RD (auth: PN), SD (auth: PO), TD (auth: Ph), UD (auth: Pi), VD (auth: Pj), WD (auth: Pk), XD (auth: Pl), YD (auth: Pm), ZD (auth: Pn), AE (auth: Po), BE (auth: Pp), CE (auth: Pq), DE (auth: Pr), EE (auth: Ps), FE (auth: Pt), GE (auth: RC), HE (auth: RD), IE (auth: RE), JE (auth: RF), KE (auth: RG), LE (auth: RH), ME (auth: RI), NE (auth: RJ), OE (auth: RK), PE (auth: RL), QE (auth: RM), RE (auth: RN), SE (auth: RO), TE (auth: RR), UE (auth: RS), VE (auth: RT), WE (auth: Rk), XE (auth: Rl), YE (auth: Rm), ZE (auth: Rn), AF (auth: Ro), BF (auth: Rp), CF (auth: Rq), DF (auth: Rr), EF (auth: Rs), FF (auth: Rt)
Chain Length:163
Number of Molecules:78
Biological Source:Escherichia phage T4

UniProt ID:A0A7S9SVI2

Ligand Molecules

Primary Citation

In situ Atomic Structure of Phage T4 Head-Tail Connector Complex Shows Molecular Gates Open for Genome Ejection and DNA Pushed into the Tail Tube

Fokine, A, Zhu, J, Klose, T, Vago, F, Arnaud, C, Wang, Z, Khare, B, Rossmann, M.G, Chen, Z, Sun, L, Fang, Q, Kuhn, R, Rao, V.B.Show

To Be Published ? ? ? (?)
