ISDA: 9MN1

Deposition Date 2024-12-20

Release Date 2026-01-21

Last Version Date 2026-01-21

Entry Detail

PDB ID:

9MN1

Keywords:

CHAPERONE

Title:

E. coli SR1 single-ring GroEL oligomer

Biological Source:

Source Organism(s):

Escherichia coli (Taxon ID: 562)

Expression System(s):

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

2.40 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:60 kDa chaperonin
Gene (Uniprot):groL
Chain IDs:A, B, C, D, E, F, G, H, I, J, K, L, M, N
Chain Length:548
Number of Molecules:14
Biological Source:Escherichia coli

UniProt ID:Q548M1 EC:5.6.1.7

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:10 kDa chaperonin
Gene (Uniprot):groS
Chain IDs:O, P, Q, R, S, T, U
Chain Length:97
Number of Molecules:7
Biological Source:Escherichia coli

UniProt ID:Q7BGE6

Ligand Molecules

ADP

ATP

Primary Citation

Deciphering the unique mechanism whereby bis-sulfonamido-2-phenylbenzoxazole (PBZ) GroEL/ES inhibitors modulate chaperonin ATPase and client protein folding functions.

Stevens, M, Doud, E, Norambuena, J, Tepper, K, Trindl, C.A, Carpenter, R, Chapman, E, Boyd, J.M, Wells, C, Chen, Q, Johnson, S.M.Show

To Be Published ? ? ? (?)
