ISDA: 9LY9

Deposition Date 2025-02-19

Release Date 2025-12-31

Last Version Date 2025-12-31

Entry Detail

PDB ID:

9LY9

Keywords:

STRUCTURAL PROTEIN

Title:

Cryo-EM structure of carboxysomal mid-shell: T = 16 shell under C1 symmetry.

Biological Source:

Source Organism:

Halothiobacillus neapolitanus c2 (Taxon ID: 555778)

Host Organism:

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.71 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Major carboxysome shell protein CsoS1A
Gene (Uniprot):csoS1A
Chain IDs:A (auth: AA), B (auth: AB), C (auth: AC), D (auth: AD), E (auth: AE), F (auth: BA), G (auth: BB), H (auth: BC), I (auth: BD), J (auth: BE), K (auth: CA), L (auth: CB), M (auth: CC), N (auth: CD), O (auth: CE), P (auth: DA), Q (auth: DB), R (auth: DC), S (auth: DE), T (auth: EA), U (auth: EB), V (auth: EC), W (auth: ED), X (auth: EE), Y (auth: FA), Z (auth: FB), AA (auth: FC), BA (auth: FD), CA (auth: FE), DA (auth: GA), EA (auth: GB), FA (auth: GC), GA (auth: GD), HA (auth: GE), IA (auth: HA), JA (auth: HB), KA (auth: HC), LA (auth: HD), MA (auth: HE), NA (auth: IA), OA (auth: IB), PA (auth: IC), QA (auth: ID), RA (auth: IE), SA (auth: JA), TA (auth: JB), UA (auth: JD), VA (auth: JE), WA (auth: KA), XA (auth: KB), YA (auth: KC), ZA (auth: KD), AB (auth: KE), BB (auth: LA), CB (auth: LB), DB (auth: LC), EB (auth: LD), FB (auth: LE), GB (auth: MA), HB (auth: MB), IB (auth: MC), JB (auth: MD), KB (auth: ME), LB (auth: NA), MB (auth: NB), NB (auth: NC), OB (auth: ND), PB (auth: NE), QB (auth: OA), RB (auth: OB), SB (auth: OC), TB (auth: OD), UB (auth: OE), JC (auth: A1), KC (auth: A2), LC (auth: A3), MC (auth: A4), NC (auth: A5), OC (auth: B1), PC (auth: B2), QC (auth: B3), RC (auth: B4), SC (auth: B5), TC (auth: C1), UC (auth: C2), VC (auth: C3), WC (auth: C4), XC (auth: C5), YC (auth: D1), ZC (auth: D2), AD (auth: D3), BD (auth: D5), CD (auth: E1), DD (auth: E2), ED (auth: E4), FD (auth: E5), GD (auth: F1), HD (auth: F2), ID (auth: F3), JD (auth: F4), KD (auth: F5), LD (auth: G1), MD (auth: G2), ND (auth: G3), OD (auth: G4), PD (auth: G5), QD (auth: H1), RD (auth: H2), SD (auth: H3), TD (auth: H4), UD (auth: H5), VD (auth: I1), WD (auth: I2), XD (auth: I3), YD (auth: I4), ZD (auth: I5), AE (auth: J1), BE (auth: J2), CE (auth: J4), DE (auth: J5), EE (auth: K1), FE (auth: K2), GE (auth: K3), HE (auth: K4), IE (auth: K5), JE (auth: L1), KE (auth: L2), LE (auth: L4), ME (auth: L5), NE (auth: M1), OE (auth: M2), PE (auth: M3), QE (auth: M4), RE (auth: M5), SE (auth: N1), TE (auth: N2), UE (auth: N3), VE (auth: N4), WE (auth: N5), XE (auth: O1), YE (auth: O2), ZE (auth: O3), AF (auth: O4), BF (auth: O5), NF (auth: A0), OF (auth: A6), PF (auth: A7), QF (auth: A8), RF (auth: A9), SF (auth: B0), TF (auth: B6), UF (auth: B7), VF (auth: B8), WF (auth: B9), XF (auth: C0), YF (auth: C6), ZF (auth: C7), AG (auth: C8), BG (auth: C9), CG (auth: D0), DG (auth: D8), EG (auth: D9), FG (auth: E0), GG (auth: E6), HG (auth: E7), IG (auth: E8), JG (auth: E9), KG (auth: F0), LG (auth: F6), MG (auth: F7), NG (auth: F8), OG (auth: F9), PG (auth: G0), QG (auth: G6), RG (auth: G7), SG (auth: G8), TG (auth: G9), UG (auth: H0), VG (auth: H6), WG (auth: H7), XG (auth: H8), YG (auth: H9), ZG (auth: I0), AH (auth: I6), BH (auth: I7), CH (auth: I8), DH (auth: I9), EH (auth: J0), FH (auth: J7), GH (auth: J8), HH (auth: J9), IH (auth: K0), JH (auth: K6), KH (auth: K7), LH (auth: K8), MH (auth: K9), NH (auth: L0), OH (auth: L6), PH (auth: L7), QH (auth: L8), RH (auth: L9), SH (auth: M0), TH (auth: M6), UH (auth: M7), VH (auth: M8), WH (auth: M9), XH (auth: N0), YH (auth: N6), ZH (auth: N7), AI (auth: N8), BI (auth: N9), CI (auth: O0), DI (auth: O6), EI (auth: O7), FI (auth: O8), GI (auth: O9), UI (auth: AP), VI (auth: AQ), WI (auth: AR), XI (auth: AS), YI (auth: AT), ZI (auth: BP), AJ (auth: BQ), BJ (auth: BR), CJ (auth: BS), DJ (auth: BT), EJ (auth: CP), FJ (auth: CQ), GJ (auth: CR), HJ (auth: CS), IJ (auth: CT), JJ (auth: DP), KJ (auth: DQ), LJ (auth: DT), MJ (auth: EP), NJ (auth: EQ), OJ (auth: ER), PJ (auth: ES), QJ (auth: ET), RJ (auth: FP), SJ (auth: FQ), TJ (auth: FR), UJ (auth: FS), VJ (auth: FT), WJ (auth: GP), XJ (auth: GQ), YJ (auth: GR), ZJ (auth: GS), AK (auth: GT), BK (auth: HP), CK (auth: HQ), DK (auth: HR), EK (auth: HS), FK (auth: HT), GK (auth: IP), HK (auth: IQ), IK (auth: IR), JK (auth: IS), KK (auth: IT), LK (auth: JP), MK (auth: JQ), NK (auth: JR), OK (auth: JS), PK (auth: JT), QK (auth: KP), RK (auth: KQ), SK (auth: KR), TK (auth: KS), UK (auth: KT), VK (auth: LP), WK (auth: LQ), XK (auth: LR), YK (auth: LS), ZK (auth: LT), AL (auth: MP), BL (auth: MQ), CL (auth: MR), DL (auth: MS), EL (auth: MT), FL (auth: NP), GL (auth: NQ), HL (auth: NR), IL (auth: NS), JL (auth: NT), KL (auth: OP), LL (auth: OQ), ML (auth: OR), NL (auth: OS), OL (auth: OT), DM (auth: AG), EM (auth: AH), FM (auth: AI), GM (auth: AJ), HM (auth: AK), IM (auth: BG), JM (auth: BH), KM (auth: BI), LM (auth: BJ), MM (auth: BK), NM (auth: CG), OM (auth: CH), PM (auth: CI), QM (auth: CJ), RM (auth: CK), SM (auth: DG), TM (auth: DK), UM (auth: EG), VM (auth: EH), WM (auth: EJ), XM (auth: EK), YM (auth: FG), ZM (auth: FH), AN (auth: FI), BN (auth: FJ), CN (auth: FK), DN (auth: GG), EN (auth: GH), FN (auth: GI), GN (auth: GJ), HN (auth: GK), IN (auth: HG), JN (auth: HH), KN (auth: HI), LN (auth: HJ), MN (auth: HK), NN (auth: IG), ON (auth: IH), PN (auth: II), QN (auth: IJ), RN (auth: IK), SN (auth: JG), TN (auth: JH), UN (auth: JJ), VN (auth: JK), WN (auth: KG), XN (auth: KH), YN (auth: KJ), ZN (auth: KK), AO (auth: LG), BO (auth: LH), CO (auth: LJ), DO (auth: LK), EO (auth: MG), FO (auth: MH), GO (auth: MJ), HO (auth: NG), IO (auth: NH), JO (auth: NJ), KO (auth: NK), LO (auth: OG), MO (auth: OH), NO (auth: OJ), OO (auth: OK), CP (auth: AF), DP (auth: AL), EP (auth: AM), FP (auth: AN), GP (auth: AO), HP (auth: BF), IP (auth: BL), JP (auth: BM), KP (auth: BN), LP (auth: BO), MP (auth: CF), NP (auth: CL), OP (auth: CM), PP (auth: CN), QP (auth: CO), RP (auth: DL), SP (auth: DN), TP (auth: DO), UP (auth: EM), VP (auth: EN), WP (auth: EO), XP (auth: FM), YP (auth: FN), ZP (auth: FO), AQ (auth: GF), BQ (auth: GL), CQ (auth: GM), DQ (auth: GN), EQ (auth: GO), FQ (auth: HF), GQ (auth: HL), HQ (auth: HM), IQ (auth: HN), JQ (auth: HO), KQ (auth: IF), LQ (auth: IL), MQ (auth: IM), NQ (auth: IN), OQ (auth: IO), PQ (auth: JL), QQ (auth: JM), RQ (auth: JN), SQ (auth: JO), TQ (auth: KF), UQ (auth: KL), VQ (auth: KM), WQ (auth: KN), XQ (auth: KO), YQ (auth: LF), ZQ (auth: LL), AR (auth: LO), BR (auth: ML), CR (auth: MM), DR (auth: MN), ER (auth: MO), FR (auth: NF), GR (auth: NM), HR (auth: NN), IR (auth: NO), JR (auth: OF), KR (auth: OL), LR (auth: OM), MR (auth: ON), NR (auth: OO), BS (auth: Ae), CS (auth: Af), DS (auth: Ag), ES (auth: Ah), FS (auth: Ai), GS (auth: Be), HS (auth: Bf), IS (auth: Bg), JS (auth: Bh), KS (auth: Bi), LS (auth: Ce), MS (auth: Cf), NS (auth: Cg), OS (auth: Ch), PS (auth: Ci), QS (auth: De), RS (auth: Dg), SS (auth: Di), TS (auth: Ee), US (auth: Ef), VS (auth: Eg), WS (auth: Eh), XS (auth: Ei), YS (auth: Fe), ZS (auth: Ff), AT (auth: Fg), BT (auth: Fi), CT (auth: Ge), DT (auth: Gf), ET (auth: Gg), FT (auth: Gh), GT (auth: Gi), HT (auth: He), IT (auth: Hf), JT (auth: Hg), KT (auth: Hh), LT (auth: Hi), MT (auth: Ie), NT (auth: If), OT (auth: Ig), PT (auth: Ih), QT (auth: Ii), RT (auth: Je), ST (auth: Jf), TT (auth: Jg), UT (auth: Jh), VT (auth: Ji), WT (auth: Ke), XT (auth: Kf), YT (auth: Kg), ZT (auth: Kh), AU (auth: Ki), BU (auth: Le), CU (auth: Lf), DU (auth: Lg), EU (auth: Lh), FU (auth: Li), GU (auth: Me), HU (auth: Mf), IU (auth: Mg), JU (auth: Mh), KU (auth: Mi), LU (auth: Ne), MU (auth: Nf), NU (auth: Ng), OU (auth: Nh), PU (auth: Ni), QU (auth: Oe), RU (auth: Of), SU (auth: Og), TU (auth: Oh), UU (auth: Oi), JV (auth: AV), KV (auth: AW), LV (auth: AX), MV (auth: AY), NV (auth: AZ), OV (auth: BV), PV (auth: BW), QV (auth: BX), RV (auth: BY), SV (auth: BZ), TV (auth: CV), UV (auth: CW), VV (auth: CX), WV (auth: CY), XV (auth: CZ), YV (auth: DV), ZV (auth: DW), AW (auth: DX), BW (auth: DZ), CW (auth: EV), DW (auth: EW), EW (auth: EX), FW (auth: EY), GW (auth: EZ), HW (auth: FV), IW (auth: FW), JW (auth: FX), KW (auth: FZ), LW (auth: GV), MW (auth: GW), NW (auth: GX), OW (auth: GY), PW (auth: GZ), QW (auth: HV), RW (auth: HW), SW (auth: HX), TW (auth: HY), UW (auth: HZ), VW (auth: IV), WW (auth: IW), XW (auth: IX), YW (auth: IY), ZW (auth: IZ), AX (auth: JV), BX (auth: JW), CX (auth: JX), DX (auth: JZ), EX (auth: KV), FX (auth: KW), GX (auth: KX), HX (auth: KY), IX (auth: KZ), JX (auth: LV), KX (auth: LW), LX, MX (auth: LY), NX (auth: LZ), OX (auth: MV), PX (auth: MW), QX (auth: MX), RX (auth: MY), SX (auth: MZ), TX (auth: NV), UX (auth: NW), VX (auth: NX), WX (auth: NY), XX (auth: NZ), YX (auth: OV), ZX (auth: OW), AY (auth: OX), BY (auth: OY), CY (auth: OZ), QY (auth: AU), RY (auth: Aa), SY (auth: Ab), TY (auth: Ac), UY (auth: Ad), VY (auth: BU), WY (auth: Ba), XY (auth: Bb), YY (auth: Bc), ZY (auth: Bd), AZ (auth: CU), BZ (auth: Ca), CZ (auth: Cb), DZ (auth: Cc), EZ (auth: Cd), FZ (auth: Da), GZ (auth: Dc), HZ (auth: Dd), IZ (auth: EU), JZ (auth: Ea), KZ (auth: Eb), LZ (auth: Ec), MZ (auth: Ed), NZ (auth: FU), OZ (auth: Fa), PZ (auth: Fb), QZ (auth: Fc), RZ (auth: Fd), SZ (auth: GU), TZ (auth: Ga), UZ (auth: Gb), VZ (auth: Gc), WZ (auth: Gd), XZ (auth: HU), YZ (auth: Ha), ZZ (auth: Hb), AAA (auth: Hc), BAA (auth: Hd), CAA (auth: IU), DAA (auth: Ia), EAA (auth: Ib), FAA (auth: Ic), GAA (auth: Id), HAA (auth: Ja), IAA (auth: Jb), JAA (auth: Jc), KAA (auth: Jd), LAA (auth: KU), MAA (auth: Ka), NAA (auth: Kb), OAA (auth: Kc), PAA (auth: Kd), QAA (auth: LU), RAA (auth: La), SAA (auth: Lb), TAA (auth: Lc), UAA (auth: Ld), VAA (auth: MU), WAA (auth: Ma), XAA (auth: Mb), YAA (auth: Mc), ZAA (auth: Md), ABA (auth: NU), BBA (auth: Na), CBA (auth: Nb), DBA (auth: Nc), EBA (auth: Nd), FBA (auth: OU), GBA (auth: Oa), HBA (auth: Ob), IBA (auth: Oc), JBA (auth: Od), WBA (auth: At), XBA (auth: Au), YBA (auth: Av), ZBA (auth: Aw), ACA (auth: Ax), BCA (auth: Bt), CCA (auth: Bu), DCA (auth: Bv), ECA (auth: Bw), FCA (auth: Bx), GCA (auth: Ct), HCA (auth: Cu), ICA (auth: Cv), JCA (auth: Cw), KCA (auth: Cx), LCA (auth: Dt), MCA (auth: Du), NCA (auth: Dv), OCA (auth: Dx), PCA (auth: Et), QCA (auth: Eu), RCA (auth: Ev), SCA (auth: Ew), TCA (auth: Ex), UCA (auth: Ft), VCA (auth: Fu), WCA (auth: Fv), XCA (auth: Fw), YCA (auth: Fx), ZCA (auth: Gt), ADA (auth: Gu), BDA (auth: Gv), CDA (auth: Gw), DDA (auth: Gx), EDA (auth: Ht), FDA (auth: Hu), GDA (auth: Hv), HDA (auth: Hw), IDA (auth: Hx), JDA (auth: It), KDA (auth: Iu), LDA (auth: Iv), MDA (auth: Iw), NDA (auth: Ix), ODA (auth: Jt), PDA (auth: Ju), QDA (auth: Jw), RDA (auth: Jx), SDA (auth: Kt), TDA (auth: Ku), UDA (auth: Kv), VDA (auth: Kw), WDA (auth: Kx), XDA (auth: Lt), YDA (auth: Lu), ZDA (auth: Lv), AEA (auth: Lw), BEA (auth: Lx), CEA (auth: Mt), DEA (auth: Mu), EEA (auth: Mv), FEA (auth: Mw), GEA (auth: Mx), HEA (auth: Nt), IEA (auth: Nu), JEA (auth: Nv), KEA (auth: Nw), LEA (auth: Nx), MEA (auth: Ot), NEA (auth: Ou), OEA (auth: Ov), PEA (auth: Ow), QEA (auth: Ox), FFA (auth: Ak), GFA (auth: Al), HFA (auth: Am), IFA (auth: An), JFA (auth: Ao), KFA (auth: Bk), LFA (auth: Bl), MFA (auth: Bm), NFA (auth: Bn), OFA (auth: Bo), PFA (auth: Ck), QFA (auth: Cl), RFA (auth: Cm), SFA (auth: Cn), TFA (auth: Co), UFA (auth: Dk), VFA (auth: Dm), WFA (auth: Do), XFA (auth: Ek), YFA (auth: En), ZFA (auth: Eo), AGA (auth: Fk), BGA (auth: Fm), CGA (auth: Fn), DGA (auth: Fo), EGA (auth: Gk), FGA (auth: Gl), GGA (auth: Gm), HGA (auth: Gn), IGA (auth: Go), JGA (auth: Hk), KGA (auth: Hl), LGA (auth: Hm), MGA (auth: Hn), NGA (auth: Ho), OGA (auth: Ik), PGA (auth: Il), QGA (auth: Im), RGA (auth: In), SGA (auth: Io), TGA (auth: Jk), UGA (auth: Jl), VGA (auth: Jn), WGA (auth: Jo), XGA (auth: Kk), YGA (auth: Kl), ZGA (auth: Kn), AHA (auth: Ko), BHA (auth: Lk), CHA (auth: Ll), DHA (auth: Ln), EHA (auth: Lo), FHA (auth: Mk), GHA (auth: Ml), HHA (auth: Mn), IHA (auth: Mo), JHA (auth: Nk), KHA (auth: Nl), LHA (auth: Nn), MHA (auth: No), NHA (auth: Ok), OHA (auth: Ol), PHA (auth: On), QHA (auth: Oo), EIA (auth: Aj), FIA (auth: Ap), GIA (auth: Aq), HIA (auth: Ar), IIA (auth: As), JIA (auth: Bj), KIA (auth: Bp), LIA (auth: Bq), MIA (auth: Br), NIA (auth: Bs), OIA (auth: Cj), PIA (auth: Cp), QIA (auth: Cq), RIA (auth: Cr), SIA (auth: Cs), TIA (auth: Dp), UIA (auth: Dr), VIA (auth: Ds), WIA (auth: Ej), XIA (auth: Ep), YIA (auth: Eq), ZIA (auth: Er), AJA (auth: Es), BJA (auth: Fj), CJA (auth: Fp), DJA (auth: Fr), EJA (auth: Fs), FJA (auth: Gj), GJA (auth: Gp), HJA (auth: Gq), IJA (auth: Gr), JJA (auth: Gs), KJA (auth: Hj), LJA (auth: Hp), MJA (auth: Hq), NJA (auth: Hr), OJA (auth: Hs), PJA (auth: Ij), QJA (auth: Ip), RJA (auth: Iq), SJA (auth: Ir), TJA (auth: Is), UJA (auth: Jj), VJA (auth: Jp), WJA (auth: Jq), XJA (auth: Jr), YJA (auth: Js), ZJA (auth: Kj), AKA (auth: Kp), BKA (auth: Kq), CKA (auth: Kr), DKA (auth: Ks), EKA (auth: Lj), FKA (auth: Lp), GKA (auth: Lq), HKA (auth: Lr), IKA (auth: Ls), JKA (auth: Mj), KKA (auth: Mp), LKA (auth: Mq), MKA (auth: Mr), NKA (auth: Ms), OKA (auth: Nj), PKA (auth: Np), QKA (auth: Nq), RKA (auth: Nr), SKA (auth: Ns), TKA (auth: Oj), UKA (auth: Op), VKA (auth: Oq), WKA (auth: Or), XKA (auth: Os), LLA (auth: DD), MLA (auth: JC), OLA (auth: D4), PLA (auth: J3), RLA (auth: D7), SLA (auth: J6), VLA (auth: DS), XLA (auth: EI), YLA (auth: DM), DMA (auth: Dw), EMA (auth: Jv), GMA (auth: Dn), LMA (auth: DR), MMA (auth: FL), NMA (auth: LM), OMA (auth: LN), PMA (auth: NL), QMA (auth: Fh), RMA (auth: FY), SMA (auth: JY), UMA (auth: Dj), VMA (auth: Fq), XMA (auth: EL), ZMA (auth: Dh), ANA (auth: DY), BNA (auth: Db), CNA (auth: Dq), DNA (auth: L3), FNA (auth: Em), GNA (auth: DJ), HNA (auth: E3), INA (auth: DH), KNA (auth: DI), LNA (auth: D6), MNA (auth: Df), PNA (auth: JI), QNA (auth: KI), RNA (auth: LI), SNA (auth: MI), TNA (auth: NI), UNA (auth: OI), VNA (auth: FF), WNA (auth: JU), XNA (auth: El), YNA (auth: Fl), ZNA (auth: Km), AOA (auth: Nm), BOA (auth: Om), DOA (auth: DU), EOA (auth: Dl), GOA (auth: EF), HOA (auth: DF), IOA (auth: MK), JOA (auth: JF), KOA (auth: Jm), LOA (auth: Lm), MOA (auth: MF), NOA (auth: Mm)
Chain Length:98
Number of Molecules:900
Biological Source:Halothiobacillus neapolitanus c2

UniProt ID:P45689 Pfam ID:PF00936

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Carboxysome shell vertex protein CsoS4A
Gene (Uniprot):csoS4A
Chain IDs:VB (auth: PA), WB (auth: PB), XB (auth: PC), YB (auth: PD), ZB (auth: PE), CF (auth: P1), DF (auth: P2), EF (auth: P3), FF (auth: P4), GF (auth: P5), HI (auth: P6), II (auth: P7), JI (auth: P8), KI (auth: P9), LI (auth: P0), PL (auth: PP), QL (auth: PQ), RL (auth: PR), SL (auth: PS), TL (auth: PT), PO (auth: PG), QO (auth: PH), RO (auth: PI), SO (auth: PJ), TO (auth: PK), OR (auth: PL), PR (auth: PM), QR (auth: PN), RR (auth: PO), SR (auth: PF), VU (auth: Pe), WU (auth: Pf), XU (auth: Pg), YU (auth: Ph), ZU (auth: Pi), DY (auth: PV), EY (auth: PW), FY (auth: PX), GY (auth: PY), HY (auth: PZ), KBA (auth: Pa), LBA (auth: Pb), MBA (auth: Pc), NBA (auth: Pd), OBA (auth: PU), REA (auth: Pt), SEA (auth: Pu), TEA (auth: Pv), UEA (auth: Pw), VEA (auth: Px), RHA (auth: Pk), SHA (auth: Pl), THA (auth: Pm), UHA (auth: Pn), VHA (auth: Po), YKA (auth: Pp), ZKA (auth: Pq), ALA (auth: Pr), BLA (auth: Ps), CLA (auth: Pj)
Chain Length:83
Number of Molecules:60
Biological Source:Halothiobacillus neapolitanus c2

UniProt ID:O85043 Pfam ID:PF03319

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Carboxysome assembly protein CsoS2B
Gene (Uniprot):csoS2
Chain IDs:AC (auth: XA), BC (auth: XB), CC (auth: XC), DC (auth: XE), EC (auth: YA), FC (auth: YB), GC (auth: YC), HC (auth: YD), IC (auth: YE), HF (auth: X1), IF (auth: X2), JF (auth: Y1), KF (auth: Y2), LF (auth: Y4), MF (auth: Y5), MI (auth: X6), NI (auth: X9), OI (auth: X0), PI (auth: Y6), QI (auth: Y7), RI (auth: Y8), SI (auth: Y9), TI (auth: Y0), UL (auth: XP), VL (auth: XQ), WL (auth: XR), XL (auth: XT), YL (auth: YP), ZL (auth: YQ), AM (auth: YR), BM (auth: YS), CM (auth: YT), UO (auth: XG), VO (auth: XH), WO (auth: XK), XO (auth: YG), YO (auth: YH), ZO (auth: YI), AP (auth: YJ), BP (auth: YK), TR (auth: XL), UR (auth: XO), VR (auth: XF), WR (auth: YL), XR (auth: YM), YR (auth: YN), ZR (auth: YO), AS (auth: YF), AV (auth: Xe), BV (auth: Xf), CV (auth: Xg), DV (auth: Xi), EV (auth: Ye), FV (auth: Yf), GV (auth: Yg), HV (auth: Yh), IV (auth: Yi), IY (auth: XV), JY (auth: XW), KY (auth: XZ), LY (auth: YV), MY (auth: YW), NY (auth: YX), OY (auth: YY), PY (auth: YZ), PBA (auth: Xd), QBA (auth: XU), RBA (auth: Ya), SBA (auth: Yb), TBA (auth: Yc), UBA (auth: Yd), VBA (auth: YU), WEA (auth: Xt), XEA (auth: Xu), YEA (auth: Xv), ZEA (auth: Xx), AFA (auth: Yt), BFA (auth: Yu), CFA (auth: Yv), DFA (auth: Yw), EFA (auth: Yx), WHA (auth: Xk), XHA (auth: Xl), YHA (auth: Xo), ZHA (auth: Yk), AIA (auth: Yl), BIA (auth: Ym), CIA (auth: Yn), DIA (auth: Yo), DLA (auth: Xp), ELA (auth: Xs), FLA (auth: Xj), GLA (auth: Yp), HLA (auth: Yq), ILA (auth: Yr), JLA (auth: Ys), KLA (auth: Yj), NLA (auth: XD), QLA (auth: X4), TLA (auth: X7), ULA (auth: X8), WLA (auth: XS), ZLA (auth: Xh), AMA (auth: XY), BMA (auth: Xb), CMA (auth: Xc), FMA (auth: Xw), HMA (auth: Xn), IMA (auth: Xq), JMA (auth: Xr), KMA (auth: X5), TMA (auth: XX), WMA (auth: XJ), YMA (auth: XM), ENA (auth: Y3), JNA (auth: Xa), NNA (auth: XN), ONA (auth: X3), COA (auth: XI), FOA (auth: Xm)
Chain Length:869
Number of Molecules:120
Biological Source:Halothiobacillus neapolitanus c2

UniProt ID:O85041 Pfam ID:PF12288

Ligand Molecules

Primary Citation

Symmetry-adjusted cryo-EM analysis unveils the detailed linker protein CsoS2 interactions within the alpha-carboxysome shell.

Li, J, Li, T, Wang, S, Zhang, Y.Z, Liu, L.N, Wang, P.Show

Plant Physiol. 198 ? ? (2025)

PMID: 40341945 DOI: 10.1093/plphys/kiaf165

Abstact

Excessive symmetry in cryo-EM data processing can distort key structural details of bacterial microcompartments, highlighting the importance of balanced symmetry for accurate structural insights.
