9L60 image
Deposition Date 2024-12-23
Release Date 2025-12-31
Last Version Date 2025-12-31
Entry Detail
PDB ID:
9L60
Keywords:
MEMBRANE PROTEIN
Title:
Gi-bound kappa opioid receptor in complex with dynorphin and positive allosteric modulator MPAM-15
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Rattus norvegicus (Taxon ID: 10116)
Bos taurus (Taxon ID: 9913)
Expression System(s):
Spodoptera frugiperda
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.90 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9L60 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(i) subunit alpha-1
Gene (Uniprot):GNAI1
Mutagens:G203A,A326S
Chain IDs:A
Chain Length:354
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63096 Pfam ID:PF00503
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1
Gene (Uniprot):Gnb1
Chain IDs:B
Chain Length:353
Number of Molecules:1
Biological Source:Rattus norvegicus
UniProt ID:P54311 Pfam ID:PF00400, PF25391
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2
Gene (Uniprot):GNG2
Chain IDs:C
Chain Length:71
Number of Molecules:1
Biological Source:Bos taurus
UniProt ID:P63212 Pfam ID:PF00631
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Kappa-type opioid receptor
Gene (Uniprot):OPRK1
Chain IDs:D
Chain Length:397
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P41145 Pfam ID:PF00001
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Dynorphin A(1-13)
Gene (Uniprot):PDYN
Chain IDs:E (auth: P)
Chain Length:13
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P01213
Ligand Molecules
A1D6C
CLR
Primary Citation
Structure-based design of an opioid receptor modulator for enhanced morphine analgesia
To Be Published ? ? ? (?)
Primary Citation of related structures
9L60
