9KZU image
Deposition Date 2024-12-11
Release Date 2025-12-03
Last Version Date 2025-12-17
Entry Detail
PDB ID:
9KZU
Keywords:
RIBOSOME
Title:
Cryo-EM structure of the HCV IRES-dependently initiated CMV-stalled 80S ribosome (non-rotated state) in complexed with eIF3
Biological Source:
Source Organism(s):
Hepacivirus hominis (Taxon ID: 3052230)
Homo sapiens (Taxon ID: 9606)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.00 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9KZU validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit A
Gene (Uniprot):EIF3A
Chain IDs:HC (auth: 3a)
Chain Length:1382
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q14152 Pfam ID:PF22591, PF01399
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit C
Gene (Uniprot):EIF3C
Chain IDs:JC (auth: 3c)
Chain Length:913
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q99613 Pfam ID:PF05470, PF01399, PF26569
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit D
Gene (Uniprot):EIF3D
Chain IDs:LC (auth: 3d)
Chain Length:548
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:O15371 Pfam ID:PF05091
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit E
Gene (Uniprot):EIF3E
Chain IDs:IC (auth: 3e)
Chain Length:445
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P60228 Pfam ID:PF09440, PF01399, PF21357
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit F
Gene (Uniprot):EIF3F
Chain IDs:GC (auth: 3f)
Chain Length:357
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:O00303 Pfam ID:PF01398, PF13012
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit H
Gene (Uniprot):EIF3H
Chain IDs:KC (auth: 3h)
Chain Length:352
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:O15372 Pfam ID:PF01398, PF19445
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit K
Gene (Uniprot):EIF3K
Chain IDs:MC (auth: 3k)
Chain Length:218
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q9UBQ5 Pfam ID:PF10075
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit L
Gene (Uniprot):EIF3L
Chain IDs:NC (auth: 3l)
Chain Length:564
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q9Y262 Pfam ID:PF10255
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Eukaryotic translation initiation factor 3 subunit M
Gene (Uniprot):EIF3M
Chain IDs:FC (auth: 3m)
Chain Length:374
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q7L2H7 Pfam ID:PF01399, PF18005
Polymer Type:polyribonucleotide
Molecule:28S ribosomal RNA
Chain IDs:A (auth: L5)
Chain Length:5070
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:5S_ribosomal_RNA
Chain IDs:B (auth: L7)
Chain Length:120
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:5.8S_ribosomal_RNA
Chain IDs:C (auth: L8)
Chain Length:156
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L8
Gene (Uniprot):RPL8
Chain IDs:D (auth: LA)
Chain Length:257
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62917 Pfam ID:PF00181, PF03947
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L3
Gene (Uniprot):RPL3
Chain IDs:E (auth: LB)
Chain Length:403
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P39023 Pfam ID:PF00297
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L4
Gene (Uniprot):RPL4
Chain IDs:F (auth: LC)
Chain Length:427
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P36578 Pfam ID:PF00573, PF14374
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L5
Gene (Uniprot):RPL5
Chain IDs:G (auth: LD)
Chain Length:125
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46777 Pfam ID:PF17144, PF14204
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L6
Gene (Uniprot):RPL6
Chain IDs:H (auth: LE)
Chain Length:288
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q02878 Pfam ID:PF03868, PF01159
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L7
Gene (Uniprot):RPL7
Chain IDs:I (auth: LF)
Chain Length:110
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P18124 Pfam ID:PF08079, PF00327
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L7a
Gene (Uniprot):RPL7A
Chain IDs:J (auth: LG)
Chain Length:266
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62424 Pfam ID:PF01248
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L9
Gene (Uniprot):RPL9, RPL9P7, RPL9P8, RPL9P9
Chain IDs:K (auth: LH)
Chain Length:192
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P32969 Pfam ID:PF00347
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L10-like
Gene (Uniprot):RPL10L
Chain IDs:L (auth: LI)
Chain Length:214
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q96L21 Pfam ID:PF00252
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L11
Gene (Uniprot):RPL11
Chain IDs:M (auth: LJ)
Chain Length:178
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62913 Pfam ID:PF00281, PF00673
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L13
Gene (Uniprot):RPL13
Chain IDs:N (auth: LL)
Chain Length:51
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P26373 Pfam ID:PF01294
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L14
Gene (Uniprot):RPL14
Chain IDs:O (auth: LM)
Chain Length:128
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P50914 Pfam ID:PF01929
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L15
Gene (Uniprot):RPL15
Chain IDs:P (auth: LN)
Chain Length:204
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61313 Pfam ID:PF00827
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L13a
Gene (Uniprot):RPL13A
Chain IDs:Q (auth: LO)
Chain Length:106
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P40429 Pfam ID:PF00572
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L17
Gene (Uniprot):RPL17
Chain IDs:R (auth: LP)
Chain Length:184
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P18621 Pfam ID:PF00237
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L18
Gene (Uniprot):RPL18
Chain IDs:S (auth: LQ)
Chain Length:188
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q07020 Pfam ID:PF17135
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L19
Gene (Uniprot):RPL19
Chain IDs:T (auth: LR)
Chain Length:137
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P84098 Pfam ID:PF01280, PF25476
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L18a
Gene (Uniprot):RPL18A
Chain IDs:U (auth: LS)
Chain Length:176
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q02543 Pfam ID:PF01775
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L21
Gene (Uniprot):RPL21
Chain IDs:V (auth: LT)
Chain Length:160
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46778 Pfam ID:PF01157
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L22
Gene (Uniprot):RPL22
Chain IDs:W (auth: LU)
Chain Length:128
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P35268 Pfam ID:PF01776
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L23
Gene (Uniprot):RPL23
Chain IDs:X (auth: LV)
Chain Length:140
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62829 Pfam ID:PF00238
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L24
Gene (Uniprot):RPL24
Chain IDs:Y (auth: LW)
Chain Length:157
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P83731 Pfam ID:PF01246
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L23a
Gene (Uniprot):RPL23A
Chain IDs:Z (auth: LX)
Chain Length:156
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62750 Pfam ID:PF03939, PF00276
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L26
Gene (Uniprot):RPL26
Chain IDs:AA (auth: LY)
Chain Length:145
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61254 Pfam ID:PF16906, PF00467
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L27
Gene (Uniprot):RPL27
Chain IDs:BA (auth: LZ)
Chain Length:136
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61353 Pfam ID:PF00467, PF01777
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L27a
Gene (Uniprot):RPL27A
Chain IDs:CA (auth: La)
Chain Length:257
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46776 Pfam ID:PF00828
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L29
Gene (Uniprot):RPL29
Chain IDs:DA (auth: Lb)
Chain Length:403
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P47914 Pfam ID:PF01779
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L30
Gene (Uniprot):RPL30
Chain IDs:EA (auth: Lc)
Chain Length:427
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62888 Pfam ID:PF01248
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L31
Gene (Uniprot):RPL31
Chain IDs:FA (auth: Ld)
Chain Length:125
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62899 Pfam ID:PF01198
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L32
Gene (Uniprot):RPL32
Chain IDs:GA (auth: Le)
Chain Length:288
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62910 Pfam ID:PF01655
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L35a
Gene (Uniprot):RPL35A
Chain IDs:HA (auth: Lf)
Chain Length:110
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P18077 Pfam ID:PF01247
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L34
Gene (Uniprot):RPL34
Chain IDs:IA (auth: Lg)
Chain Length:266
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P49207 Pfam ID:PF01199
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L35
Gene (Uniprot):RPL35
Chain IDs:JA (auth: Lh)
Chain Length:192
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P42766 Pfam ID:PF00831
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L36
Gene (Uniprot):RPL36
Chain IDs:KA (auth: Li)
Chain Length:214
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:Q9Y3U8 Pfam ID:PF01158
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L37
Gene (Uniprot):RPL37
Chain IDs:LA (auth: Lj)
Chain Length:178
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61927 Pfam ID:PF01907
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L38
Gene (Uniprot):RPL38
Chain IDs:MA (auth: Lk)
Chain Length:70
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63173 Pfam ID:PF01781
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L39
Gene (Uniprot):RPL39
Chain IDs:NA (auth: Ll)
Chain Length:51
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62891 Pfam ID:PF00832
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ubiquitin-60S ribosomal protein L40
Gene (Uniprot):UBA52
Chain IDs:OA (auth: Lm)
Chain Length:128
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62987 Pfam ID:PF00240, PF01020
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L41
Gene (Uniprot):RPL41
Chain IDs:PA (auth: Ln)
Chain Length:204
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62945 Pfam ID:PF05162
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L36a
Gene (Uniprot):RPL36A
Chain IDs:QA (auth: Lo)
Chain Length:106
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P83881 Pfam ID:PF00935
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L37a
Gene (Uniprot):RPL37A
Chain IDs:RA (auth: Lp)
Chain Length:184
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61513 Pfam ID:PF01780
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:60S ribosomal protein L28
Gene (Uniprot):RPL28
Chain IDs:SA (auth: Lr)
Chain Length:137
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46779 Pfam ID:PF01778
Polymer Type:polyribonucleotide
Molecule:18S ribosomal RNA
Chain IDs:TA (auth: S2)
Chain Length:1869
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Small ribosomal subunit protein uS2
Gene (Uniprot):RPSA
Chain IDs:UA (auth: SA)
Chain Length:115
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P08865 Pfam ID:PF00318, PF16122
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S3a
Gene (Uniprot):RPS3A
Chain IDs:VA (auth: SB)
Chain Length:84
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P61247 Pfam ID:PF01015
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S2
Gene (Uniprot):RPS2
Chain IDs:PB (auth: SC)
Chain Length:293
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P15880 Pfam ID:PF00333, PF03719
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S3
Gene (Uniprot):RPS3
Chain IDs:WA (auth: SD)
Chain Length:56
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P23396 Pfam ID:PF07650, PF00189
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S4, X isoform
Gene (Uniprot):RPS4X
Chain IDs:XA (auth: SE)
Chain Length:59
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62701 Pfam ID:PF08071, PF00900, PF00467, PF16121
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S5
Gene (Uniprot):RPS5
Chain IDs:YA (auth: SF)
Chain Length:132
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46782 Pfam ID:PF00177
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S6
Gene (Uniprot):RPS6
Chain IDs:QB (auth: SG)
Chain Length:249
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62753 Pfam ID:PF01092
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S7
Gene (Uniprot):RPS7
Chain IDs:ZA (auth: SH)
Chain Length:194
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62081 Pfam ID:PF01251
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S8
Gene (Uniprot):RPS8
Chain IDs:AB (auth: SI)
Chain Length:208
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62241 Pfam ID:PF01201
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S9
Gene (Uniprot):RPS9
Chain IDs:RB (auth: SJ)
Chain Length:194
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46781 Pfam ID:PF00163, PF01479
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S10
Gene (Uniprot):RPS10
Chain IDs:BB (auth: SK)
Chain Length:165
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P46783 Pfam ID:PF03501
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S11
Gene (Uniprot):RPS11
Chain IDs:CB (auth: SL)
Chain Length:158
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62280 Pfam ID:PF16205, PF00366
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S13
Gene (Uniprot):RPS13
Chain IDs:TB (auth: SN)
Chain Length:151
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62277 Pfam ID:PF08069, PF00312
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S14
Gene (Uniprot):RPS14
Chain IDs:UB (auth: SO)
Chain Length:151
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62263 Pfam ID:PF00411
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S15
Gene (Uniprot):RPS15
Chain IDs:DB (auth: SP)
Chain Length:145
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62841 Pfam ID:PF00203
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S16
Gene (Uniprot):RPS16
Chain IDs:EB (auth: SQ)
Chain Length:146
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62249 Pfam ID:PF00380
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S17
Gene (Uniprot):RPS17
Chain IDs:FB (auth: SR)
Chain Length:135
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P08708 Pfam ID:PF00833
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S18
Gene (Uniprot):RPS18
Chain IDs:GB (auth: SS)
Chain Length:152
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62269 Pfam ID:PF00416
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S19
Gene (Uniprot):RPS19
Chain IDs:HB (auth: ST)
Chain Length:145
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P39019 Pfam ID:PF01090
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S20
Gene (Uniprot):RPS20
Chain IDs:IB (auth: SU)
Chain Length:119
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P60866 Pfam ID:PF00338
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S21
Gene (Uniprot):RPS21
Chain IDs:JB (auth: SV)
Chain Length:83
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63220 Pfam ID:PF01249
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S15a
Gene (Uniprot):RPS15A
Chain IDs:VB (auth: SW)
Chain Length:130
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62244 Pfam ID:PF00410
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S23
Gene (Uniprot):RPS23
Chain IDs:KB (auth: SX)
Chain Length:143
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62266 Pfam ID:PF00164
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S24
Gene (Uniprot):RPS24
Chain IDs:WB (auth: SY)
Chain Length:133
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62847 Pfam ID:PF01282
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S25
Gene (Uniprot):RPS25
Chain IDs:XB (auth: SZ)
Chain Length:125
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62851 Pfam ID:PF03297
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S26
Gene (Uniprot):RPS26
Chain IDs:LB (auth: Sa)
Chain Length:115
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62854 Pfam ID:PF01283
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S27
Gene (Uniprot):RPS27
Chain IDs:YB (auth: Sb)
Chain Length:84
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P42677 Pfam ID:PF01667
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S28
Gene (Uniprot):RPS28
Chain IDs:MB (auth: Sc)
Chain Length:293
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62857 Pfam ID:PF01200
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S29
Gene (Uniprot):RPS29
Chain IDs:NB (auth: Sd)
Chain Length:56
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62273 Pfam ID:PF00253
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S30
Gene (Uniprot):FAU
Chain IDs:ZB (auth: Se)
Chain Length:59
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62861 Pfam ID:PF04758
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:40S ribosomal protein S12
Gene (Uniprot):RPS12
Chain IDs:SB (auth: Sf)
Chain Length:132
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P25398 Pfam ID:PF01248
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Receptor of activated protein C kinase 1
Gene (Uniprot):RACK1
Chain IDs:OB (auth: Sg)
Chain Length:249
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63244 Pfam ID:PF00400
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ubiquitin-40S ribosomal protein S27a
Gene (Uniprot):RPS27A
Chain IDs:AC (auth: sh)
Chain Length:194
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P62979 Pfam ID:PF00240, PF01599
Polymer Type:polyribonucleotide
Molecule:mRNA
Chain IDs:BC (auth: zv)
Chain Length:19
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:nascent peptide
Chain IDs:CC (auth: zx)
Chain Length:31
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:P-site tRNA
Chain IDs:DC (auth: zy)
Chain Length:75
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polyribonucleotide
Molecule:HCV IRES
Chain IDs:EC (auth: zz)
Chain Length:332
Number of Molecules:1
Biological Source:Hepacivirus hominis
Ligand Molecules
MG
ZN
Primary Citation
Structural insights into the role of eIF3 in translation mediated by the HCV IRES.
Proc.Natl.Acad.Sci.USA 122 e2505538122 e2505538122 (2025)
PMID: 41337487 DOI: 10.1073/pnas.2505538122

Abstact

The genomes of various RNA viruses and a subset of human genes contain structured RNA elements termed internal ribosomal entry sites (IRESs) to initiate translation in a cap-independent manner. The well-studied IRES from Hepatitis C virus (HCV) binds to eukaryotic initiation factor 3 (eIF3), but how the HCV IRES harnesses eIF3 for viral translation remains unclear. Here, we determined multiple cryo-EM structures in which the HCV IRES binds simultaneously to the ribosome and eIF3, covering steps from initiation to elongation. The eIF3 core subunits are displaced from the ribosome by binding more tightly to subdomain IIIb of the HCV IRES. However, cross-linking mass spectrometry suggested that the eIF3 noncore subunits in the HCV-IRES-mediated elongation complex remain in similar positions on the ribosome to those observed in the cap-mediated initiation complex. This currently determined configuration of eIF3 core and noncore subunits reveals the mechanisms through which the HCV IRES overcomes the competition with the host mRNA and promotes viral mRNA translation by utilizing eIF3. Interestingly, cryo-EM structures also revealed that the N-terminal domain of the eIF3 c-subunit (eIF3c-NTD) binds to the large ribosomal subunit (60S) during elongation. These findings suggest that eIF3 contributes to HCV IRES-mediated translation not only during initiation but also elongation and potentially in reinitiation. The interaction between the eIF3c-NTD and the 60S ribosome is likely to occur in general translation processes as well, contributing to 60S joining or eIF3 stabilization on the elongating ribosome.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
9KZX
9KKF
9KN5
9KN6
Feedback Form
Name
Email
Institute
Feedback
