9KJY image
Deposition Date 2024-11-12
Release Date 2025-11-12
Last Version Date 2025-12-17
Entry Detail
PDB ID:
9KJY
Title:
Cryo-EM structure of the Retron-Eco7 complex (state 2)
Biological Source:
Source Organism(s):
Escherichia coli (Taxon ID: 562)
Expression System(s):
Method Details:
Experimental Method:
Resolution:
2.61 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:RNA-directed DNA polymerase
Chain IDs:A
Chain Length:322
Number of Molecules:1
Biological Source:Escherichia coli
Polymer Type:polypeptide(L)
Molecule:AAA family ATPase
Chain IDs:B, C, D, E
Chain Length:550
Number of Molecules:4
Biological Source:Escherichia coli
Polymer Type:polypeptide(L)
Molecule:TIGR02646 family protein
Chain IDs:F, G
Chain Length:266
Number of Molecules:2
Biological Source:Escherichia coli
Polymer Type:polyribonucleotide
Molecule:msrRNA
Chain IDs:H
Chain Length:146
Number of Molecules:1
Biological Source:Escherichia coli
Polymer Type:polydeoxyribonucleotide
Molecule:msdDNA
Chain IDs:I
Chain Length:77
Number of Molecules:1
Biological Source:Escherichia coli
Primary Citation
Structural mechanism of the Retron-Eco7 anti-phage defense system.
Nat Commun 16 10821 10821 (2025)
PMID: 41330933 DOI: 10.1038/s41467-025-66589-9

Abstact

Retrons are prokaryotic genetic elements involved in anti-phage defense and consist of a non-coding RNA, a reverse transcriptase (RT), and various effector proteins. Retron-Eco7 (previously known as Retron-Ec78) from Escherichia coli encodes two effector proteins (the PtuA ATPase and the PtuB nuclease) and degrades the host tRNATyr upon phage infection, thereby protecting host cells against invading phages. However, its defense mechanism remains elusive. Here, we report the cryo-electron microscopy (cryo-EM) structures of the Retron-Eco7 complex, comprising the RT, multicopy single-stranded DNA (msDNA), PtuA, and PtuB. The Retron-Eco7 structures reveal that the RT-msDNA complex associates with two PtuA-PtuB complexes, potentially inhibiting their nuclease activity and suppressing bacterial growth arrest prior to phage infection. Furthermore, the phage-encoded D15 nuclease acts as a trigger for the Retron-Eco7 system and cleaves the msDNA bound to the complex, facilitating the dissociation of PtuA-PtuB from RT-msDNA. Our data indicate that msDNA cleavage by D15 is the initial step required for the specific cleavage of the host tRNATyr by the PtuA-PtuB nuclease, which leads to abortive infection. Overall, this study provides mechanistic insights into the Retron-Eco7 system and highlights the diversity of prokaryotic anti-phage defense mechanisms.
