9KFL image
Deposition Date 2024-11-06
Release Date 2025-11-12
Last Version Date 2025-11-12
Entry Detail
PDB ID:
9KFL
Keywords:
ONCOPROTEIN
Title:
KRAS G12V and peptide complex
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Escherichia coli BL21(DE3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
3.45 Å
R-Value Free:
0.23
R-Value Work:
0.18
R-Value Observed:
0.19
Space Group:
P 1
9KFL validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Isoform 2B of GTPase KRas
Gene (Uniprot):KRAS
Mutagens:G12V
Chain IDs:A, B (auth: D), C (auth: E), D (auth: H), E (auth: K)
Chain Length:168
Number of Molecules:5
Biological Source:Homo sapiens
UniProt ID:P01116 Pfam ID:PF00071 EC:3.6.5.2
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:TIG3 peptide
Gene (Uniprot):PLAAT4
Chain IDs:F (auth: P), G (auth: Y)
Chain Length:8
Number of Molecules:2
Biological Source:Homo sapiens
UniProt ID:Q9UL19
Ligand Molecules
GDP
MG
Primary Citation
KRAS G12V and TIG3 peptide complex
To Be Published ? ? ? (?)
