ISDA: 9IVM

Deposition Date 2024-07-24

Release Date 2024-11-13

Last Version Date 2024-12-25

Entry Detail

PDB ID:

9IVM

Keywords:

MEMBRANE PROTEIN

Title:

Cryo-EM structure of the GLP-1(9-36)-bound human GLP-1R-Gs complex in the presence of LSN3318839

Biological Source:

Source Organism:

Homo sapiens (Taxon ID: 9606)

Host Organism:

Trichoplusia ni

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.22 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(i) subunit alpha-1,Guanine nucleotide-binding protein G(s) subunit alpha isoforms short
Gene (Uniprot):GNAS, GNAI1
Chain IDs:A
Chain Length:361
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P63096,P63092 Pfam ID:PF00503

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1
Gene (Uniprot):GNB1
Chain IDs:B
Chain Length:345
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P62873 Pfam ID:PF00400

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2
Gene (Uniprot):GNG2
Chain IDs:C (auth: G)
Chain Length:70
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P59768 Pfam ID:PF00631

Polymer Type:polypeptide(L)
Molecule:Nanobody-35
Chain IDs:D (auth: N)
Chain Length:140
Number of Molecules:1
Biological Source:Homo sapiens

Polymer Type:polypeptide(L)
Molecule:GLP-1(9-36)
Chain IDs:E (auth: P)
Chain Length:28
Number of Molecules:1
Biological Source:Homo sapiens

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Glucagon-like peptide 1 receptor
Gene (Uniprot):GLP1R
Chain IDs:F (auth: R)
Chain Length:440
Number of Molecules:1
Biological Source:Homo sapiens

UniProt ID:P43220 Pfam ID:PF02793, PF00002

Ligand Molecules
