ISDA: 9HZ8

Deposition Date 2025-01-13

Release Date 2025-12-10

Last Version Date 2025-12-10

Entry Detail

PDB ID:

9HZ8

Keywords:

VIRAL PROTEIN

Title:

Agrobacterium phage 7-7-1 capsid

Biological Source:

Source Organism:

Agrobacterium phage 7-7-1 (Taxon ID: 1161931)

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.40 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Major capsid protein
Gene (Uniprot):7-7-1_000115
Chain IDs:A, B, C, D (auth: E), E (auth: F), L (auth: S), M (auth: T), N (auth: U), O (auth: V), P (auth: W), Q (auth: X), X (auth: k), Y (auth: l), Z (auth: m), AA (auth: u), BA (auth: o), PA (auth: D)
Chain Length:135
Number of Molecules:17
Biological Source:Agrobacterium phage 7-7-1

UniProt ID:J7F9G3 Pfam ID:PF05065

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Structural protein
Gene (Uniprot):7-7-1_000116
Chain IDs:F (auth: G), G (auth: H), H (auth: I), I (auth: J), J (auth: K), K (auth: L), R (auth: Z), S (auth: a), T (auth: b), U (auth: c), V (auth: d), W (auth: Y), CA (auth: z), DA (auth: 1), EA (auth: 2), FA (auth: 3), GA (auth: 4), HA (auth: 5), IA (auth: 6), JA (auth: 7), KA (auth: 8), LA (auth: 9), MA (auth: 0), NA (auth: AA), OA (auth: AB), QA (auth: p), RA (auth: q), SA (auth: r), TA (auth: s), UA (auth: t)
Chain Length:135
Number of Molecules:30
Biological Source:Agrobacterium phage 7-7-1

UniProt ID:J7FAS3

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Structural protein
Gene (Uniprot):7-7-1_000122
Chain IDs:VA (auth: M), WA (auth: N), XA (auth: O), YA (auth: P), ZA (auth: Q)
Chain Length:469
Number of Molecules:5
Biological Source:Agrobacterium phage 7-7-1

UniProt ID:J7F8Z7

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Structural protein
Gene (Uniprot):7-7-1_000117A
Chain IDs:AB (auth: R), BB (auth: e), CB (auth: f), DB (auth: g), EB (auth: h), FB (auth: i), GB (auth: j), HB (auth: n), IB (auth: v), JB (auth: w), KB (auth: x), LB (auth: y)
Chain Length:469
Number of Molecules:12
Biological Source:Agrobacterium phage 7-7-1

UniProt ID:J7F8Z6

Ligand Molecules

Primary Citation

Using cryogenic electron micrography methods to gain insight into structure and initial host attachment of the fagellotrophic bacteriophage 7-7-1

Noteborn, W.E.M, Hoeksma, T, Ouyang, R, Briegel, A, Afonine, P.V, Poon, B.K, Read, R.J, Sobolev, O.V, Terwilliger, T.C, Urzhumtsev, A, Adams, P.D.Show

To Be Published ? ? ? (?)
