9HLS image
Deposition Date 2024-12-05
Release Date 2025-09-03
Last Version Date 2025-09-10
Entry Detail
PDB ID:
9HLS
Keywords:
Title:
Structure of A16/G9 (vaccinia virus) in complex with VHH D07, VHH B01 and VHH C05
Biological Source:
Source Organism:
Method Details:
Experimental Method:
Resolution:
3.20 Å
R-Value Free:
0.29
R-Value Work:
0.23
R-Value Observed:
0.23
Space Group:
C 1 2 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Virion membrane protein OPG143
Gene (Uniprot):OPG143
Chain IDs:A, F
Chain Length:358
Number of Molecules:2
Biological Source:Vaccinia virus Western Reserve
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Entry-fusion complex protein OPG094
Gene (Uniprot):OPG094
Chain IDs:B, G
Chain Length:334
Number of Molecules:2
Biological Source:Vaccinia virus Western Reserve
Polymer Type:polypeptide(L)
Molecule:VHH D07
Chain IDs:C, H
Chain Length:154
Number of Molecules:2
Biological Source:Vicugna pacos
Polymer Type:polypeptide(L)
Molecule:VHH B01
Chain IDs:D, I
Chain Length:156
Number of Molecules:2
Biological Source:Vicugna pacos
Polymer Type:polypeptide(L)
Molecule:VHH C05
Chain IDs:E (auth: J), J (auth: E)
Chain Length:156
Number of Molecules:2
Biological Source:Vicugna pacos
Primary Citation

Abstact

Monkeypox virus (MPXV) is a poxvirus endemic to Central and West Africa with high epidemic potential. Poxviruses enter host cells via a conserved entry-fusion complex (EFC), which mediates viral fusion to the cell membrane. The EFC is a promising therapeutic target, but the absence of structural data has limited the development of fusion-inhibiting treatments. Here, we investigated A16/G9, a subcomplex of the EFC that controls fusion timing. Using cryo-electron microscopy, we showed how A16/G9 interacts with A56/K2, a viral fusion suppressor that prevents superinfection. Immunization with A16/G9 elicited a protective immune response in mice. Using X-ray crystallography, we characterized two neutralizing antibodies and engineered a chimeric antibody that cross-neutralizes several poxviruses more efficiently than 7D11, the most potent antibody targeting the EFC described to date. These findings highlight the potential of A16/G9 as a candidate for subunit vaccines and identify regions of the EFC as targets for antiviral development.
