9GNI image
Deposition Date 2024-09-03
Release Date 2025-09-17
Last Version Date 2025-09-17
Entry Detail
PDB ID:
9GNI
Keywords:
NUCLEAR PROTEIN
Title:
NONO/SFPQ filament: composite structure
Biological Source:
Source Organism(s):
Cricetulus griseus (Taxon ID: 10029)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.90 Å
Aggregation State:
FILAMENT
Reconstruction Method:
SINGLE PARTICLE
9GNI validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Splicing factor proline/glutamine rich (polypyrimidine tract binding protein associated)
Gene (Uniprot):Sfpq
Chain IDs:A (auth: AA), C (auth: AC), E (auth: AE), G (auth: AG), I (auth: BA), K (auth: BC), M (auth: BE), O (auth: BG), Q (auth: CA), S (auth: CC), U (auth: CE), W (auth: CG), Y (auth: DA), AA (auth: DC), CA (auth: DG), EA (auth: DE)
Chain Length:703
Number of Molecules:16
Biological Source:Cricetulus griseus
UniProt ID:A0A8C2LX33 Pfam ID:PF00076, PF08075
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Non-POU domain-containing octamer-binding protein isoform X2
Gene (Uniprot):Nono
Chain IDs:B (auth: AB), D (auth: AD), F (auth: AF), H (auth: AH), J (auth: BB), L (auth: BD), N (auth: BF), P (auth: BH), R (auth: CB), T (auth: CD), V (auth: CF), X (auth: CH), Z (auth: DB), BA (auth: DD), DA (auth: DH), FA (auth: DF)
Chain Length:472
Number of Molecules:16
Biological Source:Cricetulus griseus
UniProt ID:A0A8C2L8F1 Pfam ID:PF00076, PF08075
Ligand Molecules
NA
Primary Citation
A filamentous scaffold for gene regulation
to be published ? ? ? (?)
Primary Citation of related structures
9GLC
9GLD
