9ETH image
Deposition Date 2024-03-26
Release Date 2025-02-26
Last Version Date 2025-02-26
Entry Detail
PDB ID:
9ETH
Keywords:
Title:
Complex structure of IL-36R D1-D2 domain with 36R-P192 and BI655130 Fab
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.30 Å
R-Value Free:
0.23
R-Value Work:
0.21
R-Value Observed:
0.21
Space Group:
C 2 2 21
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:BI00655130 Fab heavy chain
Chain IDs:A (auth: H)
Chain Length:221
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:BI00655130 Fab light chain
Chain IDs:B (auth: L)
Chain Length:215
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Molecule:ACE-PHE-VAL-GLU-5CW-3PN-TRP-ASP-TYR-VAL-CHG-6G5-SER-GLU-CYS-NH2
Chain IDs:C (auth: P)
Chain Length:16
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polypeptide(L)
Molecule:Interleukin-1 receptor-like 2
Gene (Uniprot):IL1RL2
Chain IDs:D (auth: R)
Chain Length:207
Number of Molecules:1
Biological Source:Homo sapiens
Primary Citation
Discovery of selective low molecular weight interleukin-36 receptor antagonists by encoded library technologies.
Nat Commun 16 1669 1669 (2025)
PMID: 39955284 DOI: 10.1038/s41467-025-56601-7

Abstact

Interleukin-36 receptor (IL-36R), belonging to the IL-1 receptor family, is crucial for host defense and tissue repair. Targeting cytokine receptors with low molecular weight (LMW) compounds remains challenging due to their interaction with the large surface area of cytokine. In this study, two encoded library technologies are used to identify LMW molecules binding to IL-36R's extracellular domain. The mRNA-based display technique identifies 36R-P138, a macrocyclic peptide blocking IL-36R signaling. Importantly, its optimized analog (36R-P192) also effectively suppresses expression of marker genes induced by IL-36 in human skin biopsies. DNA encoded libraries (DEL) screening delivers 36R-D481, a high affinity LMW IL-36R binder, effectively inhibiting IL-36 signaling. X-ray crystallography analysis reveals that both the cyclic peptide and DEL-compound bind to the IL-36R's D1 domain, potentially disrupting IL-36 cytokine binding. This study demonstrates that it is possible to target a cytokine receptor within the IL-1 receptor family using a small molecule ( < 1000 Da).
