9E7M image
Deposition Date 2024-11-03
Release Date 2025-11-05
Last Version Date 2025-11-05
Entry Detail
PDB ID:
9E7M
Keywords:
VIRAL PROTEIN
Title:
In situ cryoEM structure of bacteriophage Ur-lambda tail tip complex
Biological Source:
Source Organism:
Escherichia phage Lambda (Taxon ID: 2681611)
Host Organism:
Escherichia coli K-12
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.37 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9E7M validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tape measure protein
Gene (Uniprot):H
Chain IDs:A (auth: Ha), C (auth: Hb), E (auth: Hc)
Chain Length:32
Number of Molecules:3
Biological Source:Escherichia phage Lambda
UniProt ID:P03736
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tail tip assembly protein I
Gene (Uniprot):I
Chain IDs:B (auth: Ia), D (auth: Ib)
Chain Length:90
Number of Molecules:2
Biological Source:Escherichia phage Lambda
UniProt ID:P03730
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tail tip assembly protein I
Gene (Uniprot):I
Chain IDs:F (auth: Ic)
Chain Length:90
Number of Molecules:1
Biological Source:Escherichia phage Lambda
UniProt ID:P03730
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tip attachment protein J
Gene (Uniprot):J
Chain IDs:G (auth: Ja), H (auth: Jb), I (auth: Jc)
Chain Length:835
Number of Molecules:3
Biological Source:Escherichia phage Lambda
UniProt ID:P03749 Pfam ID:PF13550
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tail tip protein L
Gene (Uniprot):L
Chain IDs:J (auth: Lc), K (auth: Lb), L (auth: La)
Chain Length:232
Number of Molecules:3
Biological Source:Escherichia phage Lambda
UniProt ID:P03738 Pfam ID:PF05100
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tail tip protein M
Gene (Uniprot):M
Chain IDs:Y (auth: Ma), Z (auth: Mb), AA (auth: Mc), BA (auth: Md), CA (auth: Me), DA (auth: Mf)
Chain Length:109
Number of Molecules:6
Biological Source:Escherichia phage Lambda
UniProt ID:P03737 Pfam ID:PF05939
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tail fiber protein
Gene (Uniprot):stf
Chain IDs:M (auth: Ta), N (auth: Tb), O (auth: Tc), P (auth: Td), Q (auth: Te), R (auth: Tf), S (auth: Tg), T (auth: Tl), U (auth: Th), V (auth: Ti), W (auth: Tj), X (auth: Tk)
Chain Length:94
Number of Molecules:12
Biological Source:Escherichia phage Lambda
UniProt ID:P03764 Pfam ID:PF08400
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tail tube protein
Gene (Uniprot):V
Chain IDs:EA (auth: Va), FA (auth: Vb), GA (auth: Vc), HA (auth: Vd), IA (auth: Ve), JA (auth: Vf)
Chain Length:152
Number of Molecules:6
Biological Source:Escherichia phage Lambda
UniProt ID:P03733 Pfam ID:PF16461
Ligand Molecules
SF4
Primary Citation
Structural basis of bacteriophage Ur-lambda infection initiation
To Be Published ? ? ? (?)
Primary Citation of related structures
9E7M
