Deposition Date 2024-10-22
Release Date 2025-09-24
Last Version Date 2025-10-08
Entry Detail
PDB ID:
9E2T
Title:
Structure of a de novo designed interleukin-21 mimetic complex with IL-21R and IL-2Rg
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.28 Å
R-Value Free:
0.24
R-Value Work:
0.19
R-Value Observed:
0.20
Space Group:
P 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:21h10
Chain IDs:A, D, G, I
Chain Length:102
Number of Molecules:4
Biological Source:synthetic construct
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Interleukin-21 receptor
Gene (Uniprot):IL21R
Chain IDs:B, E, H, J
Chain Length:212
Number of Molecules:4
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cytokine receptor common subunit gamma
Gene (Uniprot):IL2RG
Chain IDs:C, F
Chain Length:203
Number of Molecules:2
Biological Source:Homo sapiens
Primary Citation

Abstact

Long-standing goals of cancer immunotherapy are to activate cytotoxic antitumor T cells across a range of affinities for tumor antigens while suppressing regulatory T cells. Computational protein design has enabled the precise tailoring of proteins to meet specific needs. Here, we report a de novo designed IL-21 mimic, 21h10, with high stability and signaling potency in humans and mice. In murine and ex vivo human organotypic tumor models, 21h10 showed robust antitumor activity, with more prolonged signaling and stronger antitumor activity than native IL-21. 21h10 induced pancreatitis that could be mitigated by TNF blockade without compromising antitumor efficacy. Although antidrug antibodies to 21h10 formed, they were not neutralizing. 21h10 induced highly cytotoxic T cells with a range of affinities, robustly expanding intratumoral low-affinity cytotoxic T cells and driving high expression of IFN-γ and granzyme B compared with native IL-21, while increasing the frequency of IFN-γ+ T helper 1 cells and reducing regulatory T cells. The full human-mouse cross-reactivity, high stability and potency, and low-affinity antitumor responses support the translational potential of 21h10.
