9CON image
Deposition Date 2024-07-17
Release Date 2026-01-28
Last Version Date 2026-01-28
Entry Detail
PDB ID:
9CON
Keywords:
IMMUNE SYSTEM
Title:
Human Kv1.3-H451V with A0194009G09 nanobodies conformation 1
Biological Source:
Source Organism(s):
Homo sapiens (Taxon ID: 9606)
Aequorea victoria (Taxon ID: 6100)
Lama glama (Taxon ID: 9844)
Expression System(s):
Homo sapiens, Escherichia coli 'bl21-gold(de3)plyss ag'
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.06 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
9CON validation report
Macromolecular Entities
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Potassium voltage-gated channel subfamily A member 3/mVenus fusion protein,Green fluorescent protein
Gene (Uniprot):KCNA3, GFP
Chain IDs:A, C, D (auth: B), E (auth: D)
Chain Length:856
Number of Molecules:4
Biological Source:Homo sapiens, Aequorea victoria
UniProt ID:P22001,P42212 Pfam ID:PF02214, PF00520
Polymer Type:polypeptide(L)
Molecule:A0194009G09 nanobody
Chain IDs:B (auth: E), F, G, H
Chain Length:126
Number of Molecules:4
Biological Source:Lama glama
Ligand Molecules
K
Primary Citation
Human Kv1.3-H451V with A0194009G09 nanobodies conformation 1
To Be Published ? ? ? (?)
Primary Citation of related structures
9CON
