9C13 image
Deposition Date 2024-05-28
Release Date 2025-11-05
Last Version Date 2025-11-05
Entry Detail
PDB ID:
9C13
Keywords:
CELL CYCLE
Title:
XMAP215 TOG5 interaction with GMPCPP tubulin lattice
Biological Source:
Source Organism:
Xenopus laevis (Taxon ID: 8355)
Bos taurus (Taxon ID: 9913)
Host Organism:
Escherichia coli BL21
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
2.89 Å
Aggregation State:
FILAMENT
Reconstruction Method:
HELICAL
9C13 validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tubulin alpha chain
Gene (Uniprot):LOC100141266
Chain IDs:C (auth: A), D (auth: C)
Chain Length:451
Number of Molecules:2
Biological Source:Bos taurus
UniProt ID:F2Z4C1 Pfam ID:PF00091, PF03953
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Tubulin beta-2B chain
Gene (Uniprot):TUBB2B
Chain IDs:A (auth: B), B (auth: D)
Chain Length:445
Number of Molecules:2
Biological Source:Bos taurus
UniProt ID:Q6B856 Pfam ID:PF00091, PF03953
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cytoskeleton-associated protein 5-A,Cytoskeleton-associated protein 5-A,Green fluorescent protein
Gene (Uniprot):ckap5-a
Chain IDs:E
Chain Length:541
Number of Molecules:1
Biological Source:Xenopus laevis
UniProt ID:Q9PT63 Pfam ID:PF21041
Ligand Molecules
G2P
GTP
MG
Primary Citation
Structure and function of XMAP215s C terminal domains in microtubule nucleation
To Be Published ? ? ? (?)
Primary Citation of related structures
9C13
