8YNF image
Deposition Date 2024-03-11
Release Date 2025-09-17
Last Version Date 2025-09-17
Entry Detail
PDB ID:
8YNF
Keywords:
IMMUNE SYSTEM
Title:
Structure of Duffy Antigen Receptor for Chemokines (DARC)/ACKR1 in complex with the chemokine, CXCL8
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Spodoptera frugiperda
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
3.65 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
8YNF validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Atypical chemokine receptor 1
Gene (Uniprot):ACKR1
Chain IDs:A (auth: B), D (auth: A)
Chain Length:392
Number of Molecules:2
Biological Source:Homo sapiens
UniProt ID:Q16570
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:IL-8(9-77)
Gene (Uniprot):CXCL8
Chain IDs:B (auth: D), C (auth: E), E (auth: G), F (auth: H)
Chain Length:79
Number of Molecules:4
Biological Source:Homo sapiens
UniProt ID:P10145 Pfam ID:PF00048
Ligand Molecules
NA
Primary Citation
Structure of Duffy Antigen Receptor for Chemokines (DARC)/ACKR1 in complex with the chemokine, CXCL8
To Be Published ? ? ? (?)
Primary Citation of related structures
8YNF
