8Y5P image
Deposition Date 2024-01-31
Release Date 2025-08-13
Last Version Date 2025-08-13
Entry Detail
PDB ID:
8Y5P
Keywords:
RIBOSOME
Title:
E.coli transcription translation coupling complex in TTC-B state 4 (subclass 1) containing mRNA with 24-mer spacer, NusG, NusA, fMet-tRNA(iMet), Phe-tRNA(Phe), and viomycin
Biological Source:
Source Organism:
Escherichia coli K-12 (Taxon ID: 83333)
synthetic construct (Taxon ID: 32630)
Host Organism:
Escherichia coli BL21(DE3)
Method Details:
Experimental Method:
ELECTRON MICROSCOPY
Resolution:
6.50 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
8Y5P validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Elongation factor G
Gene (Uniprot):fusA
Chain IDs:NB (auth: 0)
Chain Length:716
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A6M8 Pfam ID:PF00009, PF03144, PF14492, PF03764, PF00679 EC:3.6.5.3
Polymer Type:polyribonucleotide
Molecule:23S rRNA
Chain IDs:YA (auth: 1)
Chain Length:2904
Number of Molecules:1
Biological Source:Escherichia coli K-12
Polymer Type:polyribonucleotide
Molecule:5S rRNA
Chain IDs:ZA (auth: 2)
Chain Length:120
Number of Molecules:1
Biological Source:Escherichia coli K-12
Polymer Type:polyribonucleotide
Molecule:16S rRNA
Chain IDs:AB (auth: 3)
Chain Length:1542
Number of Molecules:1
Biological Source:Escherichia coli K-12
Polymer Type:polyribonucleotide
Molecule:mRNA
Chain IDs:BB (auth: 4)
Chain Length:41
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polyribonucleotide
Molecule:tRNA(fMet)
Chain IDs:LB (auth: 6)
Chain Length:77
Number of Molecules:1
Biological Source:Escherichia coli K-12
Polymer Type:polydeoxyribonucleotide
Molecule:templete DNA strand
Chain IDs:CB (auth: 8)
Chain Length:37
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polydeoxyribonucleotide
Molecule:non-templete DNA strand
Chain IDs:DB (auth: 9)
Chain Length:37
Number of Molecules:1
Biological Source:synthetic construct
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L31
Gene (Uniprot):rpmE
Chain IDs:A
Chain Length:70
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7M9 Pfam ID:PF01197
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase subunit alpha
Gene (Uniprot):rpoA
Chain IDs:EB (auth: A1), FB (auth: A2)
Chain Length:329
Number of Molecules:2
Biological Source:Escherichia coli K-12
UniProt ID:P0A7Z4 Pfam ID:PF01193, PF01000, PF03118 EC:2.7.7.6
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L32
Gene (Uniprot):rpmF
Chain IDs:B
Chain Length:57
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7N4 Pfam ID:PF01783
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase subunit beta'
Gene (Uniprot):rpoC
Chain IDs:GB (auth: B1)
Chain Length:1407
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A8T7 Pfam ID:PF04997, PF00623, PF04983, PF05000, PF04998 EC:2.7.7.6
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase subunit beta
Gene (Uniprot):rpoB
Chain IDs:HB (auth: B2)
Chain Length:1342
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A8V2 Pfam ID:PF04563, PF04561, PF04565, PF10385, PF00562, PF04560 EC:2.7.7.6
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L33
Gene (Uniprot):rpmG
Chain IDs:C
Chain Length:209
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7N9 Pfam ID:PF00471
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L34
Gene (Uniprot):rpmH
Chain IDs:D
Chain Length:46
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7P5 Pfam ID:PF00468
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L35
Gene (Uniprot):rpmI
Chain IDs:E
Chain Length:179
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7Q1 Pfam ID:PF01632
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L36
Gene (Uniprot):rpmJ
Chain IDs:F
Chain Length:38
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7Q6 Pfam ID:PF00444
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S2
Gene (Uniprot):rpsB
Chain IDs:G
Chain Length:241
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7V0 Pfam ID:PF00318
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S3
Gene (Uniprot):rpsC
Chain IDs:H
Chain Length:233
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7V3 Pfam ID:PF07650, PF00189
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S4
Gene (Uniprot):rpsD
Chain IDs:I
Chain Length:206
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7V8 Pfam ID:PF00163, PF01479
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S5
Gene (Uniprot):rpsE
Chain IDs:J
Chain Length:167
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7W1 Pfam ID:PF00333, PF03719
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S6, fully modified isoform
Gene (Uniprot):rpsF
Chain IDs:K
Chain Length:123
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P02358 Pfam ID:PF01250
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S7
Gene (Uniprot):rpsG
Chain IDs:L
Chain Length:179
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P02359 Pfam ID:PF00177
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S8
Gene (Uniprot):rpsH
Chain IDs:M
Chain Length:130
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7W7 Pfam ID:PF00410
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S9
Gene (Uniprot):rpsI
Chain IDs:N
Chain Length:127
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7X3 Pfam ID:PF00380
Polymer Type:polypeptide(L)
Molecule:Transcription termination/antitermination protein NusA
Chain IDs:JB (auth: NA)
Chain Length:495
Number of Molecules:1
Biological Source:Escherichia coli K-12
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Transcription termination/antitermination protein NusG
Gene (Uniprot):nusG
Chain IDs:KB (auth: NG)
Chain Length:181
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AFG0 Pfam ID:PF02357, PF00467
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S10
Gene (Uniprot):rpsJ
Chain IDs:O
Chain Length:117
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7R5 Pfam ID:PF00338
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S11
Gene (Uniprot):rpsK
Chain IDs:P
Chain Length:115
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7R9 Pfam ID:PF00411
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S12
Gene (Uniprot):rpsL
Chain IDs:Q
Chain Length:118
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7S3 Pfam ID:PF00164
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S13
Gene (Uniprot):rpsM
Chain IDs:R
Chain Length:118
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7S9 Pfam ID:PF00416
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S14
Gene (Uniprot):rpsN
Chain IDs:S
Chain Length:101
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AG59 Pfam ID:PF00253
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S15
Gene (Uniprot):rpsO
Chain IDs:T
Chain Length:89
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0ADZ4 Pfam ID:PF00312
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S16
Gene (Uniprot):rpsP
Chain IDs:U
Chain Length:82
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7T3 Pfam ID:PF00886
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S17
Gene (Uniprot):rpsQ
Chain IDs:V
Chain Length:84
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AG63 Pfam ID:PF00366
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S18
Gene (Uniprot):rpsR
Chain IDs:W
Chain Length:75
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7T7 Pfam ID:PF01084
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA-directed RNA polymerase subunit omega
Gene (Uniprot):rpoZ
Chain IDs:IB (auth: W0)
Chain Length:91
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A800 Pfam ID:PF01192 EC:2.7.7.6
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S19
Gene (Uniprot):rpsS
Chain IDs:X
Chain Length:92
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7U3 Pfam ID:PF00203
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S20
Gene (Uniprot):rpsT
Chain IDs:Y
Chain Length:63
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7U7 Pfam ID:PF01649
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:30S ribosomal protein S21
Gene (Uniprot):rpsU
Chain IDs:Z
Chain Length:59
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P68679 Pfam ID:PF01165
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Large ribosomal subunit protein uL1
Gene (Uniprot):rplA
Chain IDs:MB (auth: a)
Chain Length:70
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7L0 Pfam ID:PF00687
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L2
Gene (Uniprot):rplB
Chain IDs:AA (auth: b)
Chain Length:57
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P60422 Pfam ID:PF00181, PF03947
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L3
Gene (Uniprot):rplC
Chain IDs:BA (auth: c)
Chain Length:209
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P60438 Pfam ID:PF00297
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L4
Gene (Uniprot):rplD
Chain IDs:CA (auth: d)
Chain Length:46
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P60723 Pfam ID:PF00573
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L5
Gene (Uniprot):rplE
Chain IDs:DA (auth: e)
Chain Length:179
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P62399 Pfam ID:PF00673, PF00281
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L6
Gene (Uniprot):rplF
Chain IDs:EA (auth: f)
Chain Length:38
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AG55 Pfam ID:PF00347
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L9
Gene (Uniprot):rplI
Chain IDs:FA (auth: g)
Chain Length:241
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7R1 Pfam ID:PF01281, PF03948
Protein Blast
Polymer Type:polypeptide(D)
Molecule:Viomycin
Chain IDs:OB (auth: h)
Chain Length:233
Number of Molecules:1
Biological Source:synthetic construct
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L11
Gene (Uniprot):rplK
Chain IDs:GA (auth: i)
Chain Length:206
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7J7 Pfam ID:PF03946, PF00298
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L13
Gene (Uniprot):rplM
Chain IDs:HA (auth: j)
Chain Length:167
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AA10 Pfam ID:PF00572
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L14
Gene (Uniprot):rplN
Chain IDs:IA (auth: k)
Chain Length:123
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0ADY3 Pfam ID:PF00238
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L15
Gene (Uniprot):rplO
Chain IDs:JA (auth: l)
Chain Length:179
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P02413 Pfam ID:PF00828
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L16
Gene (Uniprot):rplP
Chain IDs:KA (auth: m)
Chain Length:130
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0ADY7 Pfam ID:PF00252
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L17
Gene (Uniprot):rplQ
Chain IDs:LA (auth: n)
Chain Length:127
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AG44 Pfam ID:PF01196
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L18
Gene (Uniprot):rplR
Chain IDs:MA (auth: o)
Chain Length:117
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0C018 Pfam ID:PF00861
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L19
Gene (Uniprot):rplS
Chain IDs:NA (auth: p)
Chain Length:115
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7K6 Pfam ID:PF01245
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L20
Gene (Uniprot):rplT
Chain IDs:OA (auth: q)
Chain Length:118
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7L3 Pfam ID:PF00453
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L21
Gene (Uniprot):rplU
Chain IDs:PA (auth: r)
Chain Length:118
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AG48 Pfam ID:PF00829
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L22
Gene (Uniprot):rplV
Chain IDs:QA (auth: s)
Chain Length:101
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P61175 Pfam ID:PF00237
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L23
Gene (Uniprot):rplW
Chain IDs:RA (auth: t)
Chain Length:89
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0ADZ0 Pfam ID:PF00276
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L24
Gene (Uniprot):rplX
Chain IDs:SA (auth: u)
Chain Length:82
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P60624 Pfam ID:PF00467, PF17136
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L25
Gene (Uniprot):rplY
Chain IDs:TA (auth: v)
Chain Length:84
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P68919 Pfam ID:PF01386
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L27
Gene (Uniprot):rpmA
Chain IDs:UA (auth: w)
Chain Length:75
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7L8 Pfam ID:PF01016
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L28
Gene (Uniprot):rpmB
Chain IDs:VA (auth: x)
Chain Length:92
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7M2 Pfam ID:PF00830
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L29
Gene (Uniprot):rpmC
Chain IDs:WA (auth: y)
Chain Length:63
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0A7M6 Pfam ID:PF00831
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:50S ribosomal protein L30
Gene (Uniprot):rpmD
Chain IDs:XA (auth: z)
Chain Length:59
Number of Molecules:1
Biological Source:Escherichia coli K-12
UniProt ID:P0AG51 Pfam ID:PF00327
Ligand Molecules
GDP
MG
PO4
Peptide-like Molecules
PRD_000226
Primary Citation
E.coli transcription translation coupling complex in TTC-B state 4 (subclass 1) containing mRNA with 24-mer spacer, NusG, NusA, fMet-tRNA(iMet), Phe-tRNA(Phe), and viomycin
To be published ? ? ? (?)
Primary Citation of related structures
8Y5P
