8UFF image
Deposition Date 2023-10-04
Release Date 2024-10-09
Last Version Date 2024-10-09
Entry Detail
PDB ID:
8UFF
Keywords:
TRANSCRIPTION
Title:
Human PU.1 ETS-Domain (165-270) Bound to d(AATAAAAGGAAGTGGG) in Ternary Complex with DB1976
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
synthetic construct (Taxon ID: 32630)
Host Organism:
Escherichia coli
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.66 Å
R-Value Free:
0.20
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
P 1 21 1
8UFF validation report
Macromolecular Entities
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(*AP*AP*TP*AP*AP*AP*AP*GP*GP*AP*AP*GP*TP*GP*GP*G)-3')
Chain IDs:A (auth: C)
Chain Length:16
Number of Molecules:1
Biological Source:synthetic construct
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(*TP*CP*CP*CP*AP*CP*TP*TP*CP*CP*TP*TP*TP*TP*AP*T)-3')
Chain IDs:B (auth: D)
Chain Length:16
Number of Molecules:1
Biological Source:synthetic construct
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Transcription factor PU.1
Gene (Uniprot):SPI1
Chain IDs:C (auth: F)
Chain Length:106
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P17947 Pfam ID:PF00178
Ligand Molecules
Y5U
Primary Citation
Structural studies on the PU.1 inhibitory mechanism by diamidine minor groove binders
To Be Published ? ? ? (?)
Primary Citation of related structures
8T4N
