Deposition Date 2024-02-15
Release Date 2025-09-03
Last Version Date 2025-09-03
Entry Detail
PDB ID:
8S1O
Keywords:
SIGNALING PROTEIN
Title:
Crystal structure of human Rac1-GDP-Pi
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Escherichia coli BL21(DE3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
2.27 Å
R-Value Free:
0.26
R-Value Work:
0.20
R-Value Observed:
0.21
Space Group:
C 2 2 21
8S1O validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Ras-related C3 botulinum toxin substrate 1
Gene (Uniprot):RAC1
Chain IDs:A
Chain Length:177
Number of Molecules:1
Biological Source:Homo sapiens
UniProt ID:P63000 Pfam ID:PF00071 EC:3.6.5.2
Ligand Molecules
GDP
MG
PO4
Primary Citation
Crystal structure of human Rac1-GDP-Pi
To Be Published ? ? ? (?)
