ISDA: 8K27

Deposition Date 2023-07-12

Release Date 2024-07-17

Last Version Date 2024-10-16

Entry Detail

PDB ID:

8K27

Keywords:

RNA BINDING PROTEIN/DNA/RNA

Title:

ICP1 Csy-dsDNA complex (partial duplex)

Biological Source:

Source Organism:

Vibrio phage ICP1_2004_A (Taxon ID: 979527)

Host Organism:

Escherichia coli

Method Details:

Experimental Method:

ELECTRON MICROSCOPY

Resolution:

3.60 Å

Aggregation State:

PARTICLE

Reconstruction Method:

SINGLE PARTICLE

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Csy1
Gene (Uniprot):TUST1-10_00450
Chain IDs:A
Chain Length:179
Number of Molecules:1
Biological Source:Vibrio phage ICP1_2004_A

UniProt ID:F1D5V8

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Csy2
Gene (Uniprot):TUST1-10_00445
Chain IDs:B
Chain Length:248
Number of Molecules:1
Biological Source:Vibrio phage ICP1_2004_A

UniProt ID:F1D5V7 Pfam ID:PF09614

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Csy3
Gene (Uniprot):TUST1-10_00440
Chain IDs:C (auth: D), G (auth: C), H (auth: G), I (auth: F), J (auth: E), K (auth: H)
Chain Length:306
Number of Molecules:6
Biological Source:Vibrio phage ICP1_2004_A

UniProt ID:F1D5V6 Pfam ID:PF09615

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Csy4
Gene (Uniprot):TUST1-10_00435
Chain IDs:L (auth: I)
Chain Length:168
Number of Molecules:1
Biological Source:Vibrio phage ICP1_2004_A

UniProt ID:F1D5V5 Pfam ID:PF09618

Polymer Type:polyribonucleotide
Molecule:RNA (60-MER)
Chain IDs:D (auth: P)
Chain Length:60
Number of Molecules:1
Biological Source:Vibrio phage ICP1_2004_A

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (49-MER)
Chain IDs:E (auth: Q)
Chain Length:49
Number of Molecules:1
Biological Source:Vibrio phage ICP1_2004_A

Polymer Type:polydeoxyribonucleotide
Molecule:DNA (25-MER)
Chain IDs:F (auth: R)
Chain Length:25
Number of Molecules:1
Biological Source:Vibrio phage ICP1_2004_A

Ligand Molecules

Primary Citation

Structure of csy complex with short DNA

Zhang, L.X, Feng, Y.Show

To Be Published ? ? ? (?)

Primary Citation of related structures
