8D0Y image
Deposition Date 2022-05-26
Release Date 2023-07-19
Last Version Date 2026-01-14
Entry Detail
PDB ID:
8D0Y
Title:
Crystal Structure of HIV-1 BG505 SOSIPv8 Trimer in Complex with CD4bs targeting antibody 21N13 and interface targeting antibody 35O22 at 4.7 Angstrom
Biological Source:
Source Organism(s):
Expression System(s):
Method Details:
Experimental Method:
Resolution:
4.70 Å
R-Value Free:
0.29
R-Value Work:
0.26
R-Value Observed:
0.26
Space Group:
P 21 3
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:BG505SOSIPv8 gp41
Chain IDs:F (auth: B)
Chain Length:146
Number of Molecules:1
Biological Source:Human immunodeficiency virus 1
Polymer Type:polypeptide(L)
Molecule:35O22scFv Heavy Chain Variable
Chain IDs:A (auth: D)
Chain Length:128
Number of Molecules:1
Biological Source:Macaca mulatta
Polymer Type:polypeptide(L)
Molecule:35O22scFv Light Chain Variable
Chain IDs:B (auth: E)
Chain Length:111
Number of Molecules:1
Biological Source:Macaca mulatta
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:BG505SOSIPv8 gp120
Chain IDs:E (auth: G)
Chain Length:455
Number of Molecules:1
Biological Source:Human immunodeficiency virus 1
Polymer Type:polypeptide(L)
Molecule:21N13 Fab Heavy Chain
Chain IDs:C (auth: H)
Chain Length:225
Number of Molecules:1
Biological Source:Macaca mulatta
Polymer Type:polypeptide(L)
Molecule:21N13 Fab Light Chain
Chain IDs:D (auth: L)
Chain Length:213
Number of Molecules:1
Biological Source:Macaca mulatta
Ligand Molecules
Primary Citation

Abstact

Eliciting potent and broadly neutralizing antibodies (bnAbs) is a major goal in HIV-1 vaccine development. Here, we describe how germline-targeting immunogen BG505 SOSIP germline trimer 1.1 (GT1.1), generated through structure-based design, engages a diverse range of VRC01-class bnAb precursors. A single immunization with GT1.1 expands CD4 binding site (CD4bs)-specific VRC01-class B cells in knock-in mice and drives VRC01-class maturation. In nonhuman primates (NHPs), GT1.1 primes CD4bs-specific neutralizing serum responses. Selected monoclonal antibodies (mAbs) isolated from GT1.1-immunized NHPs neutralize fully glycosylated BG505 virus. Two mAbs, 12C11 and 21N13, neutralize subsets of diverse heterologous neutralization-resistant viruses. High-resolution structures revealed that 21N13 targets the same conserved residues in the CD4bs as VRC01-class and CH235-class bnAbs despite its low sequence similarity (~40%), whereas mAb 12C11 binds predominantly through its heavy chain complementarity-determining region 3. These preclinical data underpin the ongoing evaluation of GT1.1 in a phase 1 clinical trial in healthy volunteers.
