7ZAN image
Deposition Date 2022-03-22
Release Date 2022-10-12
Last Version Date 2024-10-16
Entry Detail
PDB ID:
7ZAN
Keywords:
Title:
Crystal Structure of human IL-17A in complex with IL-17RA and IL-17RC
Biological Source:
Source Organism:
Homo sapiens (Taxon ID: 9606)
Host Organism:
Method Details:
Experimental Method:
Resolution:
5.06 Å
R-Value Free:
0.35
R-Value Work:
0.29
R-Value Observed:
0.29
Space Group:
P 65 2 2
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Interleukin-17A
Gene (Uniprot):IL17A
Mutagens:N68D,C129S
Chain IDs:A, B
Chain Length:123
Number of Molecules:2
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Interleukin-17 receptor A
Gene (Uniprot):IL17RA
Mutagens:N49D, N206D, N265D
Chain IDs:C
Chain Length:292
Number of Molecules:1
Biological Source:Homo sapiens
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Isoform 2 of Interleukin-17 receptor C
Gene (Uniprot):IL17RC
Chain IDs:D
Chain Length:453
Number of Molecules:1
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
IL-17-induced dimerization of IL-17RA drives the formation of the IL-17 signalosome to potentiate signaling.
Cell Rep 41 111489 111489 (2022)
PMID: 36260993 DOI: 10.1016/j.celrep.2022.111489

Abstact

Signaling through innate immune receptors such as the Toll-like receptor (TLR)/interleukin-1 receptor (IL-1R) superfamily proceeds via the assembly of large membrane-proximal complexes or "signalosomes." Although structurally distinct, the IL-17 receptor family triggers cellular responses that are typical of innate immune receptors. The IL-17RA receptor subunit is shared by several members of the IL-17 family. Using a combination of crystallographic, biophysical, and mutational studies, we show that IL-17A, IL-17F, and IL-17A/F induce IL-17RA dimerization. X-ray analysis of the heteromeric IL-17A complex with the extracellular domains of the IL-17RA and IL-17RC receptors reveals that cytokine-induced IL-17RA dimerization leads to the formation of a 2:2:2 hexameric signaling assembly. Furthermore, we demonstrate that the formation of the IL-17 signalosome potentiates IL-17-induced IL-36γ and CXCL1 mRNA expression in human keratinocytes, compared with a dimerization-defective IL-17RA variant.
