Entry Detail
PDB ID:
7U8L
Title:
Crystal structure of chimeric hemagglutinin cH15/3 in complex with broad protective antibody 31.a.83
Biological Source:
Host Organism:
PDB Version:
Deposition Date:
2022-03-08
Release Date:
2022-06-08
Method Details:
Experimental Method:
Resolution:
4.56 Å
R-Value Free:
0.30
R-Value Work:
0.30
R-Value Observed:
0.30
Space Group:
P 3 2 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Description:Hemagglutinin HA1 subunit
Chain IDs:A
Chain Length:333
Number of Molecules:1
Biological Source:Influenza A virus
Polymer Type:polypeptide(L)
Description:Hemagglutinin HA2 subunit
Chain IDs:B
Chain Length:176
Number of Molecules:1
Biological Source:Influenza A virus
Polymer Type:polypeptide(L)
Description:antibody Fab heavy chain
Chain IDs:D (auth: H)
Chain Length:234
Number of Molecules:1
Biological Source:Homo sapiens
Polymer Type:polypeptide(L)
Description:Antibody Fab light chain
Chain IDs:C (auth: L)
Chain Length:214
Number of Molecules:1
Biological Source:Homo sapiens
Ligand Molecules
Primary Citation
Influenza chimeric hemagglutinin structures in complex with broadly protective antibodies to the stem and trimer interface.
Proc.Natl.Acad.Sci.USA 119 e2200821119 e2200821119 (2022)
PMID: 35594401 DOI: 10.1073/pnas.2200821119

Abstact

Influenza virus hemagglutinin (HA) has been the primary target for influenza vaccine development. Broadly protective antibodies targeting conserved regions of the HA unlock the possibility of generating universal influenza immunity. Two group 2 influenza A chimeric HAs, cH4/3 and cH15/3, were previously designed to elicit antibodies to the conserved HA stem. Here, we show by X-ray crystallography and negative-stain electron microscopy that a broadly protective antistem antibody can stably bind to cH4/3 and cH15/3 HAs, thereby validating their potential as universal vaccine immunogens. Furthermore, flexibility was observed in the head domain of the chimeric HA structures, suggesting that antibodies could also potentially interact with the head interface epitope. Our structural and binding studies demonstrated that a broadly protective antihead trimeric interface antibody could indeed target the more open head domain of the cH15/3 HA trimer. Thus, in addition to inducing broadly protective antibodies against the conserved HA stem, chimeric HAs may also be able to elicit antibodies against the conserved trimer interface in the HA head domain, thereby increasing the vaccine efficacy.
