7TRA image
Deposition Date 2022-01-28
Release Date 2022-08-10
Last Version Date 2025-05-14
Entry Detail
PDB ID:
7TRA
Title:
Cascade complex from type I-A CRISPR-Cas system
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
3.30 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CRISPR-associated helicase Cas3
Gene (Uniprot):cas3
Chain IDs:A
Chain Length:572
Number of Molecules:1
Biological Source:Pyrococcus furiosus DSM 3638
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cas8a
Gene (Uniprot):PF0637
Chain IDs:B
Chain Length:341
Number of Molecules:1
Biological Source:Pyrococcus furiosus DSM 3638
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cas11a
Gene (Uniprot):PF0643
Chain IDs:C, D, N (auth: E), O (auth: F), P (auth: G)
Chain Length:108
Number of Molecules:5
Biological Source:Pyrococcus furiosus DSM 3638
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cas7a
Gene (Uniprot):PF0642
Chain IDs:E (auth: H), F (auth: I), G (auth: J), H (auth: K), Q (auth: L), R (auth: M), S (auth: N)
Chain Length:336
Number of Molecules:7
Biological Source:Pyrococcus furiosus DSM 3638
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Cas5a
Gene (Uniprot):cas5a
Chain IDs:I (auth: O)
Chain Length:256
Number of Molecules:1
Biological Source:Pyrococcus furiosus DSM 3638
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:CRISPR-associated endonuclease Cas3-HD
Gene (Uniprot):cas3
Chain IDs:J (auth: Q)
Chain Length:219
Number of Molecules:1
Biological Source:Pyrococcus furiosus DSM 3638
Polymer Type:polyribonucleotide
Molecule:crRNA (44-MER)
Chain IDs:K (auth: R)
Chain Length:44
Number of Molecules:1
Biological Source:Escherichia coli
Polymer Type:polydeoxyribonucleotide
Molecule:Target strand DNA (44-MER)
Chain IDs:L (auth: S)
Chain Length:44
Number of Molecules:1
Biological Source:Escherichia coli
Polymer Type:polydeoxyribonucleotide
Molecule:Non-Target strand DNA (25-MER)
Chain IDs:M (auth: T)
Chain Length:25
Number of Molecules:1
Biological Source:Escherichia coli
Ligand Molecules
Primary Citation
Allosteric control of type I-A CRISPR-Cas3 complexes and establishment as effective nucleic acid detection and human genome editing tools.
Mol.Cell 82 2754 2768.e5 (2022)
PMID: 35835111 DOI: 10.1016/j.molcel.2022.06.007

Abstact

Type I CRISPR-Cas systems typically rely on a two-step process to degrade DNA. First, an RNA-guided complex named Cascade identifies the complementary DNA target. The helicase-nuclease fusion enzyme Cas3 is then recruited in trans for processive DNA degradation. Contrary to this model, here, we show that type I-A Cascade and Cas3 function as an integral effector complex. We provide four cryoelectron microscopy (cryo-EM) snapshots of the Pyrococcus furiosus (Pfu) type I-A effector complex in different stages of DNA recognition and degradation. The HD nuclease of Cas3 is autoinhibited inside the effector complex. It is only allosterically activated upon full R-loop formation, when the entire targeted region has been validated by the RNA guide. The mechanistic insights inspired us to convert Pfu Cascade-Cas3 into a high-sensitivity, low-background, and temperature-activated nucleic acid detection tool. Moreover, Pfu CRISPR-Cas3 shows robust bi-directional deletion-editing activity in human cells, which could find usage in allele-specific inactivation of disease-causing mutations.
