ISDA

Deposition Date 1998-05-20

Release Date 1998-11-11

Last Version Date 2023-08-02

Entry Detail

PDB ID:

7MSF

Keywords:

Virus/RNA

Title:

MS2 PROTEIN CAPSID/RNA COMPLEX

Biological Source:

Source Organism:

Enterobacterio phage MS2 (Taxon ID: 12022)
(Taxon ID: )

Host Organism:

Escherichia coli

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

2.80 Å

R-Value Free:

0.21

R-Value Work:

0.2

Space Group:

H 3 2

Download Validation Report

Macromolecular Entities

Protein Blast

Polymer Type:polypeptide(L)
Molecule:MS2 PROTEIN CAPSID
Chain IDs:C (auth: A), D (auth: B), E (auth: C)
Chain Length:129
Number of Molecules:3
Biological Source:Enterobacterio phage MS2

UniProt ID:P03612 Pfam ID:PF01819

Polymer Type:polyribonucleotide
Molecule:5'-R(*UP*CP*GP*CP*CP*AP*AP*CP*AP*GP*GP*CP*GP*G)-3'
Chain IDs:A (auth: R), B (auth: S)
Chain Length:14
Number of Molecules:2
Biological Source:

Primary Citation

Crystal structures of a series of RNA aptamers complexed to the same protein target.

Rowsell, S, Stonehouse, N.J, Convery, M.A, Adams, C.J, Ellington, A.D, Hirao, I, Peabody, D.S, Stockley, P.G, Phillips, S.E, Convery, M.A, Rowsell, S, Stonehouse, N.J, Ellington, A.D, Hirao, I, Murray, J.B, Peabody, D.S, Phillips, S.E, Stockley, P.G, Valegard, K, Murray, J.B, Stonehouse, N.J, Van Den Worm, S, Stockley, P.G, Liljas, L, Valegard, K, Murray, J.B, Stockley, P.G, Stonehouse, N.J, Liljas, L, Golmohammadi, R, Valegard, K, Fridborg, K, Liljas, L.Show

Nat.Struct.Biol. 5 970 975 (1998)

PMID: 9808042 DOI: 10.1038/2946

Abstact

We have determined the crystal structures, at 2.8 A resolution, of two different RNA aptamers, each bound to MS2 coat protein. One of the aptamers contains a non-Watson-Crick base pair, while the other is missing one of the unpaired adenines that make sequence-specific contacts in the wild-type complex. Despite these differences, the RNA aptamers bind in the same location on the protein as the wild-type translational operator. Comparison of these new structures with other MS2-RNA complexes allows us to refine further the definition of the minimal recognition elements and suggests a possible application of the MS2 system for routine structure determination of small nucleic acid motifs.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
