7JVB image
Deposition Date 2020-08-20
Release Date 2020-12-02
Last Version Date 2024-11-20
Entry Detail
PDB ID:
7JVB
Keywords:
Title:
Crystal structure of the SARS-CoV-2 spike receptor-binding domain (RBD) with nanobody Nb20
Biological Source:
Host Organism:
Method Details:
Experimental Method:
Resolution:
3.29 Å
R-Value Free:
0.32
R-Value Work:
0.28
R-Value Observed:
0.28
Space Group:
P 41 21 2
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Spike protein S1
Gene (Uniprot):S
Chain IDs:A, C (auth: B)
Chain Length:224
Number of Molecules:2
Biological Source:Severe acute respiratory syndrome coronavirus 2
Polymer Type:polypeptide(L)
Molecule:Nanobody Nb20
Chain IDs:B (auth: C), D
Chain Length:117
Number of Molecules:2
Biological Source:Lama glama
Ligand Molecules
Primary Citation
Versatile and multivalent nanobodies efficiently neutralize SARS-CoV-2.
Science 370 1479 1484 (2020)
PMID: 33154108 DOI: 10.1126/science.abe4747

Abstact

Cost-effective, efficacious therapeutics are urgently needed to combat the COVID-19 pandemic. In this study, we used camelid immunization and proteomics to identify a large repertoire of highly potent neutralizing nanobodies (Nbs) to the severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) spike protein receptor binding domain (RBD). We discovered Nbs with picomolar to femtomolar affinities that inhibit viral infection at concentrations below the nanograms-per-milliliter level, and we determined a structure of one of the most potent Nbs in complex with the RBD. Structural proteomics and integrative modeling revealed multiple distinct and nonoverlapping epitopes and indicated an array of potential neutralization mechanisms. We bioengineered multivalent Nb constructs that achieved ultrahigh neutralization potency (half-maximal inhibitory concentration as low as 0.058 ng/ml) and may prevent mutational escape. These thermostable Nbs can be rapidly produced in bulk from microbes and resist lyophilization and aerosolization.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
