7JSF image
Deposition Date 2020-08-14
Release Date 2020-12-16
Last Version Date 2024-03-06
Entry Detail
PDB ID:
7JSF
Keywords:
Title:
Adeno-Associated Virus Helicase domain Heptamer with ssDNA
Biological Source:
Method Details:
Experimental Method:
Resolution:
6.70 Å
Aggregation State:
PARTICLE
Reconstruction Method:
SINGLE PARTICLE
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Protein Rep68
Gene (Uniprot):Rep68
Mutations:C151S
Chain IDs:A, B, C, D, E, F, G
Chain Length:537
Number of Molecules:7
Biological Source:Adeno-associated virus - 2
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(P*TP*TP*TP*T)-3')
Chain IDs:H
Chain Length:4
Number of Molecules:1
Biological Source:synthetic construct
Ligand Molecules
Primary Citation
The Cryo-EM structure of AAV2 Rep68 in complex with ssDNA reveals a malleable AAA+ machine that can switch between oligomeric states.
Nucleic Acids Res. 48 12983 12999 (2020)
PMID: 33270897 DOI: 10.1093/nar/gkaa1133

Abstact

The adeno-associated virus (AAV) non-structural Rep proteins catalyze all the DNA transactions required for virus viability including, DNA replication, transcription regulation, genome packaging, and during the latent phase, site-specific integration. Rep proteins contain two multifunctional domains: an Origin Binding Domain (OBD) and a SF3 helicase domain (HD). Studies have shown that Rep proteins have a dynamic oligomeric behavior where the nature of the DNA substrate molecule modulates its oligomeric state. In the presence of ssDNA, Rep68 forms a large double-octameric ring complex. To understand the mechanisms underlying AAV Rep function, we investigated the cryo-EM and X-ray structures of Rep68-ssDNA complexes. Surprisingly, Rep68 generates hybrid ring structures where the OBD forms octameric rings while the HD forms heptamers. Moreover, the binding to ATPγS promotes a large conformational change in the entire AAA+ domain that leads the HD to form both heptamer and hexamers. The HD oligomerization is driven by an interdomain linker region that acts as a latch to 'catch' the neighboring HD subunit and is flexible enough to permit the formation of different stoichiometric ring structures. Overall, our studies show the structural basis of AAV Rep's structural flexibility required to fulfill its multifunctional role during the AAV life cycle.
