6Y2U image
Deposition Date 2020-02-17
Release Date 2021-03-31
Last Version Date 2024-10-23
Entry Detail
PDB ID:
6Y2U
Keywords:
TRANSFERASE
Title:
Crystal structure of the cAMP-dependent protein kinase A cocrystallized with aminofasudil and PKI (5-24)
Biological Source:
Source Organism:
Cricetulus griseus (Taxon ID: 10029)
Mus musculus (Taxon ID: 10090)
Host Organism:
Escherichia coli BL21(DE3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.93 Å
R-Value Free:
0.22
R-Value Work:
0.18
R-Value Observed:
0.18
Space Group:
P 21 21 21
6Y2U validation report
Macromolecular Entities
Protein Blast
Polymer Type:polypeptide(L)
Molecule:cAMP-dependent protein kinase catalytic subunit alpha
Gene (Uniprot):PRKACA
Chain IDs:A
Chain Length:353
Number of Molecules:1
Biological Source:Cricetulus griseus
UniProt ID:P25321 Pfam ID:PF00069 EC:2.7.11.11
Protein Blast
Polymer Type:polypeptide(L)
Molecule:cAMP-dependent protein kinase inhibitor alpha
Gene (Uniprot):Pkia
Chain IDs:B
Chain Length:20
Number of Molecules:1
Biological Source:Mus musculus
UniProt ID:P63248
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
SEP A SER modified residue
TPO A THR modified residue
Ligand Molecules
LRT
Primary Citation
Fragment based drug design - Small chemical changes of fragments effecting big changes in binding
To Be Published ? ? ? (?)
Primary Citation of related structures
6Y2U
