6JSB image
Deposition Date 2019-04-08
Release Date 2019-11-20
Last Version Date 2024-10-23
Entry Detail
PDB ID:
6JSB
Keywords:
HEME-BINDING PROTEIN
Title:
Crystal structure of Heme binding protein HtaB from Corynebacterium glutamicum
Biological Source:
Source Organism:
Corynebacterium glutamicum (strain ATCC 13032 / DSM 20300 / JCM 1318 / LMG 3730 / NCIMB 10025) (Taxon ID: 196627)
Host Organism:
Escherichia coli BL21(DE3)
Method Details:
Experimental Method:
X-RAY DIFFRACTION
Resolution:
1.70 Å
R-Value Free:
0.19
R-Value Work:
0.17
R-Value Observed:
0.17
Space Group:
C 1 2 1
6JSB validation report
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Hypothetical membrane protein
Gene (Uniprot):Cgl0392
Chain IDs:A, B
Chain Length:203
Number of Molecules:2
Biological Source:Corynebacterium glutamicum (strain ATCC 13032 / DSM 20300 / JCM 1318 / LMG 3730 / NCIMB 10025)
UniProt ID:Q8NTB5 Pfam ID:PF04213
Ligand Molecules
CA
HEM
Primary Citation
Structural basis for the heme transfer reaction in heme uptake machinery from Corynebacteria.
Chem.Commun.(Camb.) 55 13864 13867 (2019)
PMID: 31670736 DOI: 10.1039/c9cc07369h

Abstact

The crystal structures of the conserved region domains of HtaA and HtaB, which act as heme binding/transport proteins in the heme uptake machinery in Corynebacterium glutamicum, are determined for the first time. The molecular mechanism of heme transfer among these proteins is proposed based on the spectroscopic and structural analyses.

Legend

Protein

Chemical

Disease

Primary Citation of related structures
6JSB
