5ZAD image
Deposition Date 2018-02-07
Release Date 2019-03-20
Last Version Date 2023-11-22
Entry Detail
PDB ID:
5ZAD
Title:
Human topoisomerase II beta in complex with DNA
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.54 Å
R-Value Free:
0.22
R-Value Work:
0.18
R-Value Observed:
0.18
Space Group:
P 32
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:DNA topoisomerase 2-beta
Gene (Uniprot):TOP2B
Chain IDs:A, D (auth: B)
Chain Length:803
Number of Molecules:2
Biological Source:Homo sapiens
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(P*AP*GP*CP*CP*GP*AP*GP*C)-3')
Chain IDs:B (auth: C), E (auth: D)
Chain Length:8
Number of Molecules:2
Biological Source:synthetic construct
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(P*TP*GP*CP*AP*GP*CP*TP*CP*GP*GP*CP*T)-3')
Chain IDs:C (auth: F), F (auth: E)
Chain Length:12
Number of Molecules:2
Biological Source:synthetic construct
Primary Citation
Increasing the distance between two monomers of topoisomerase II beta under the action of antitumor agent 4 beta-sulfur-(benzimidazole) 4'-demethylepipodophyllotoxin.
Sci Rep 8 14949 14949 (2018)
PMID: 30297860 DOI: 10.1038/s41598-018-33366-2

Abstact

Topoisomerases II (Top2s) are a group of essential enzymes involved in replication, transcription, chromosome condensation, and segregation via altering DNA topology. The mechanism of the Top2s poisons such as etoposide (VP-16) was reported as stabilizing the Top2-DNA complex and engendering permanent DNA breakage. As the structurally similar compound of VP-16, a novel 4β-sulfur-substituted 4'-demethylepipodophyllotoxin (DMEP) derivative (compound C-Bi) with superior antitumor activity was developed in our previous study. To understand the structural basis of the compound action, the crystal structure (2.54 Å) of human Top2 β-isoform (hTop2β) cleavage complexes stabilized by compound C-Bi was determined. However, compound C-Bi was not visible in the crystal structure. Through the comparison of the structures of hTop2β-DNA-etoposide ternary complex and hTop2β-DNA binary complex, it could be observed that the distance between drug-binding sites Arg503 of the two monomers was 26.62 Å in hTop2β-DNA-etoposide ternary complex and 34.54 Å in hTop2β-DNA binary complex, respectively. Significant twist were observed in the DNA chains of binary complex. It suggested that compound C-Bi played antitumor roles through increasing spacing of hTop2β monomers. The changes in hTop2β structure further caused double changes in the torsional direction and migration distance of the DNA chains, resulting in impeding religation of DNA.
