5Z7D image
Deposition Date 2018-01-28
Release Date 2019-01-30
Last Version Date 2023-11-22
Entry Detail
PDB ID:
5Z7D
Keywords:
Title:
p204HINab-dsDNA complex structure
Biological Source:
Source Organism:
Mus musculus (Taxon ID: 10090)
Vaccinia virus (Taxon ID: 10245)
Host Organism:
Method Details:
Experimental Method:
Resolution:
4.50 Å
R-Value Free:
0.29
R-Value Work:
0.25
R-Value Observed:
0.26
Space Group:
P 65 2 2
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Interferon-activable protein 204
Gene (Uniprot):Ifi204
Chain IDs:A, B, C
Chain Length:412
Number of Molecules:3
Biological Source:Mus musculus
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(P*CP*CP*AP*TP*CP*AP*GP*AP*AP*AP*GP*AP*GP*AP*GP*C)-3')
Chain IDs:D (auth: I), F (auth: K)
Chain Length:16
Number of Molecules:2
Biological Source:Vaccinia virus
Polymer Type:polydeoxyribonucleotide
Molecule:DNA (5'-D(P*CP*CP*AP*TP*CP*AP*GP*AP*AP*AP*GP*AP*GP*AP*GP*C)-3')
Chain IDs:E (auth: J), G (auth: L)
Chain Length:16
Number of Molecules:2
Biological Source:Vaccinia virus
Ligand Molecules
Primary Citation
Structural mechanism of DNA recognition by the p204 HIN domain.
Nucleic Acids Res. ? ? ? (2021)
PMID: 33619523 DOI: 10.1093/nar/gkab076

Abstact

The interferon gamma-inducible protein 16 (IFI16) and its murine homologous protein p204 function in non-sequence specific dsDNA sensing; however, the exact dsDNA recognition mechanisms of IFI16/p204, which harbour two HIN domains, remain unclear. In the present study, we determined crystal structures of p204 HINa and HINb domains, which are highly similar to those of other PYHIN family proteins. Moreover, we obtained the crystal structure of p204 HINab domain in complex with dsDNA and provided insights into the dsDNA binding mode. p204 HINab binds dsDNA mainly through α2 helix of HINa and HINb, and the linker between them, revealing a similar HIN:DNA binding mode. Both HINa and HINb are vital for HINab recognition of dsDNA, as confirmed by fluorescence polarization assays. Furthermore, a HINa dimerization interface was observed in structures of p204 HINa and HINab:dsDNA complex, which is involved in binding dsDNA. The linker between HINa and HINb reveals dynamic flexibility in solution and changes its direction at ∼90° angle in comparison with crystal structure of HINab:dsDNA complex. These structural information provide insights into the mechanism of DNA recognition by different HIN domains, and shed light on the unique roles of two HIN domains in activating the IFI16/p204 signaling pathway.
