5MS2 image
Deposition Date 2016-12-30
Release Date 2017-04-19
Last Version Date 2024-01-17
Entry Detail
PDB ID:
5MS2
Keywords:
Title:
Crystal structure of the Legionella pneumophila effector protein RavZ in complex with human LC3B
Biological Source:
Method Details:
Experimental Method:
Resolution:
2.47 Å
R-Value Free:
0.23
R-Value Work:
0.17
R-Value Observed:
0.18
Space Group:
P 1 21 1
Macromolecular Entities
Polymer Type:polypeptide(L)
Molecule:Legionella pneumophila effector protein RavZ
Gene (Uniprot):ravZ
Chain IDs:A
Chain Length:433
Number of Molecules:1
Biological Source:Legionella pneumophila subsp. pneumophila str. Philadelphia 1
Polymer Type:polypeptide(L)
Molecule:Microtubule-associated proteins 1A/1B light chain 3B
Gene (Uniprot):MAP1LC3B
Chain IDs:B
Chain Length:124
Number of Molecules:1
Biological Source:Homo sapiens
Primary Citation
Elucidation of the anti-autophagy mechanism of the Legionella effector RavZ using semisynthetic LC3 proteins.
Elife 6 ? ? (2017)
PMID: 28395732 DOI: 10.7554/eLife.23905

Abstact

Autophagy is a conserved cellular process involved in the elimination of proteins and organelles. It is also used to combat infection with pathogenic microbes. The intracellular pathogen Legionella pneumophila manipulates autophagy by delivering the effector protein RavZ to deconjugate Atg8/LC3 proteins coupled to phosphatidylethanolamine (PE) on autophagosomal membranes. To understand how RavZ recognizes and deconjugates LC3-PE, we prepared semisynthetic LC3 proteins and elucidated the structures of the RavZ:LC3 interaction. Semisynthetic LC3 proteins allowed the analysis of structure-function relationships. RavZ extracts LC3-PE from the membrane before deconjugation. RavZ initially recognizes the LC3 molecule on membranes via its N-terminal LC3-interacting region (LIR) motif. The RavZ α3 helix is involved in extraction of the PE moiety and docking of the acyl chains into the lipid-binding site of RavZ that is related in structure to that of the phospholipid transfer protein Sec14. Thus, Legionella has evolved a novel mechanism to specifically evade host autophagy.
