4xdw image
Deposition Date 2014-12-20
Release Date 2015-07-15
Last Version Date 2023-11-08
Entry Detail
PDB ID:
4XDW
Keywords:
Title:
Crystal Structure of the L74F/M78V/I80V/L114F mutant of LEH
Biological Source:
Source Organism:
Host Organism:
Method Details:
Experimental Method:
Resolution:
2.05 Å
R-Value Free:
0.24
R-Value Work:
0.20
R-Value Observed:
0.20
Space Group:
P 1 21 1
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:Limonene-1,2-epoxide hydrolase
Gene (Uniprot):limA
Mutagens:L74F/M78V/I80V/L114F
Chain IDs:A, B (auth: E), C (auth: G), D (auth: B), E (auth: F), F (auth: H), G (auth: C), H (auth: D)
Chain Length:155
Number of Molecules:8
Biological Source:Rhodococcus erythropolis
Primary Citation
Reshaping an Enzyme Binding Pocket for Enhanced and Inverted Stereoselectivity: Use of Smallest Amino Acid Alphabets in Directed Evolution
Angew.Chem.Int.Ed.Engl. 54 12410 12415 (2015)
PMID: 25891639 DOI: 10.1002/anie.201501809

Abstact

Directed evolution based on saturation mutagenesis at sites lining the binding pocket is a commonly practiced strategy for enhancing or inverting the stereoselectivity of enzymes for use in organic chemistry or biotechnology. However, as the number of residues in a randomization site increases to five or more, the screening effort for 95 % library coverage increases astronomically until it is no longer feasible. We propose the use of a single amino acid for saturation mutagenesis at superlarge randomization sites comprising 10 or more residues. When used to reshape the binding pocket of limonene epoxide hydrolase, this strategy, which drastically reduces the search space and thus the screening effort, resulted in R,R- and S,S-selective mutants for the hydrolytic desymmetrization of cyclohexene oxide and other epoxides. X-ray crystal structures and docking studies of the mutants unveiled the source of stereoselectivity and shed light on the mechanistic intricacies of this enzyme.
