ISDA: 4O9R

Deposition Date 2014-01-02

Release Date 2014-03-05

Last Version Date 2024-10-16

Entry Detail

PDB ID:

4O9R

Keywords:

SIGNALING PROTEIN

Title:

Human Smoothened Receptor structure in complex with cyclopamine

Biological Source:

Source Organism(s):

Homo sapiens (Taxon ID: 9606)
Escherichia coli (Taxon ID: 562)

Expression System(s):

Spodoptera frugiperda

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

3.20 Å

R-Value Free:

0.27

R-Value Work:

0.23

R-Value Observed:

0.23

Space Group:

P 1 21 1

Download Validation Report

Macromolecular Entities

Protein Blast

Polymer Type:polypeptide(L)
Molecule:Smoothened homolog/Soluble cytochrome b562 chimeric protein
Gene (Uniprot):cybC, SMO
Mutagens:M1007W, H1102I, R1106L
Chain IDs:A
Chain Length:468
Number of Molecules:1
Biological Source:Homo sapiens, Escherichia coli

UniProt ID:Q99835,P0ABE7 Pfam ID:PF01534, PF07361

Ligand Molecules

CY8

Primary Citation

Lipidic cubic phase injector facilitates membrane protein serial femtosecond crystallography.

Weierstall, U, James, D, Wang, C, White, T.A, Wang, D, Liu, W, Spence, J.C, Bruce Doak, R, Nelson, G, Fromme, P, Fromme, R, Grotjohann, I, Kupitz, C, Zatsepin, N.A, Liu, H, Basu, S, Wacker, D, Han, G.W, Katritch, V, Boutet, S, Messerschmidt, M, Williams, G.J, Koglin, J.E, Marvin Seibert, M, Klinker, M, Gati, C, Shoeman, R.L, Barty, A, Chapman, H.N, Kirian, R.A, Beyerlein, K.R, Stevens, R.C, Li, D, Shah, S.T, Howe, N, Caffrey, M, Cherezov, V.Show

Nat Commun 5 3309 3309 (2014)

PMID: 24525480 DOI: 10.1038/ncomms4309

Abstact

Lipidic cubic phase (LCP) crystallization has proven successful for high-resolution structure determination of challenging membrane proteins. Here we present a technique for extruding gel-like LCP with embedded membrane protein microcrystals, providing a continuously renewed source of material for serial femtosecond crystallography. Data collected from sub-10-μm-sized crystals produced with less than 0.5 mg of purified protein yield structural insights regarding cyclopamine binding to the Smoothened receptor.
