ISDA: 4MWA

4MWA image

Deposition Date 2013-09-24

Release Date 2013-10-09

Last Version Date 2025-03-26

Entry Detail

PDB ID:

4MWA

Keywords:

Title:

1.85 Angstrom Crystal Structure of GCPE Protein from Bacillus anthracis

Biological Source:

Source Organism:

Bacillus anthracis (Taxon ID: 260799)

Host Organism:

Escherichia coli

Method Details:

Experimental Method:

X-RAY DIFFRACTION

Resolution:

1.85 Å

R-Value Free:

0.16

R-Value Work:

0.12

R-Value Observed:

0.12

Space Group:

P 3

4MWA validation report

Download Validation Report

Macromolecular Entities

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:4-hydroxy-3-methylbut-2-en-1-yl diphosphate synthase
Gene (Uniprot):ispG
Chain IDs:A, G
Chain Length:276
Number of Molecules:2
Biological Source:Bacillus anthracis

UniProt ID:Q81LV7 Pfam ID:PF04551

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:4-hydroxy-3-methylbut-2-en-1-yl diphosphate synthase
Gene (Uniprot):ispG
Chain IDs:B
Chain Length:276
Number of Molecules:1
Biological Source:Bacillus anthracis

UniProt ID:Q81LV7 Pfam ID:PF04551

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:4-hydroxy-3-methylbut-2-en-1-yl diphosphate synthase
Gene (Uniprot):ispG
Chain IDs:C
Chain Length:276
Number of Molecules:1
Biological Source:Bacillus anthracis

UniProt ID:Q81LV7 Pfam ID:PF04551

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:4-hydroxy-3-methylbut-2-en-1-yl diphosphate synthase
Gene (Uniprot):ispG
Chain IDs:D, F, H
Chain Length:276
Number of Molecules:3
Biological Source:Bacillus anthracis

UniProt ID:Q81LV7 Pfam ID:PF04551

Structures with similar UniProt ID

Protein Blast

Polymer Type:polypeptide(L)
Molecule:4-hydroxy-3-methylbut-2-en-1-yl diphosphate synthase
Gene (Uniprot):ispG
Chain IDs:E
Chain Length:276
Number of Molecules:1
Biological Source:Bacillus anthracis

UniProt ID:Q81LV7 Pfam ID:PF04551

Modified Residue

Compound ID	Chain ID	Parent Comp ID	Details	2D Image
KCX	A	LYS	LYSINE NZ-CARBOXYLIC ACID
MSE	A	MET	SELENOMETHIONINE

Ligand Molecules

CL

SO4

Primary Citation

1.85 Angstrom Crystal Structure of GCPE Protein from Bacillus anthracis.

Minasov, G, Wawrzak, Z, Brunzelle, J.S, Xu, X, Cui, H, Maltseva, N, Bishop, B, Kwon, K, Savchenko, A, Joachimiak, A, Anderson, W.F, Center for Structural Genomics of Infectious Diseases (CSGID)Show

TO BE PUBLISHED ? ? ? (?)

Primary Citation of related structures

4MWA
