4I47 image
Deposition Date 2012-11-27
Release Date 2012-12-12
Last Version Date 2024-11-20
Entry Detail
PDB ID:
4I47
Keywords:
Title:
Crystal structure of the Ribosome inactivating protein complexed with methylated guanine
Biological Source:
Source Organism:
Method Details:
Experimental Method:
Resolution:
2.65 Å
R-Value Free:
0.19
R-Value Work:
0.16
R-Value Observed:
0.16
Space Group:
H 3
Macromolecular Entities
Structures with similar UniProt ID
Protein Blast
Polymer Type:polypeptide(L)
Molecule:rRNA N-glycosidase
Gene (Uniprot):RIP
Chain IDs:A
Chain Length:246
Number of Molecules:1
Biological Source:Momordica balsamina
Modified Residue
Compound ID Chain ID Parent Comp ID Details 2D Image
ASN A ASN GLYCOSYLATION SITE
Ligand Molecules
Primary Citation
First structural evidence of sequestration of mRNA cap structures by type 1 ribosome inactivating protein from Momordica balsamina.
Proteins 81 896 905 (2013)
PMID: 23280611 DOI: 10.1002/prot.24248

Abstact

This is the first structural evidence of recognition of mRNA cap structures by a ribosome inactivating protein. It is well known that a unique cap structure is formed at the 5' end of mRNA for carrying out various processes including mRNA maturation, translation initiation, and RNA turnover. The binding studies and crystal structure determinations of type 1 ribosome inactivating protein (RIP-1) from Momordica balsamina (MbRIP-1) were carried out with mRNA cap structures including (i) N7-methyl guanine (m7G), (ii) N7-methyl guanosine diphosphate (m7GDP), and (iii) N7-methyl guanosine triphosphate (m7GTP). These compounds showed affinities to MbRIP-1 at nanomolar concentrations. The structure determinations of the complexes of MbRIP-1 with m7G, m7GDP, and m7GTP at 2.65, 1.77, and 1.75 Å resolutions revealed that all the three compounds bound to MbRIP-1 in the substrate binding site at the positions which are slightly shifted towards Glu85 as compared to those of rRNA substrates. In this position, Glu85 forms several hydrogen bonds with guanine moiety while N-7 methyl group forms van der Waals contacts. However, the guanine rings are poorly stacked in these complexes. Thus, the mode of binding by MbRIP-1 to mRNA cap structures is different which results in the inhibition of depurination. Since some viruses are known to exploit the capping property of the host, this action of MbRIP-1 may have implications for the antiviral activity of this protein in vivo. The understanding of the mode of binding of MbRIP-1 to cap structures may also assist in the design of anti-viral agents.
